2-1
2. SSB RADIOTELEPHONE
You can use the SSB communication in the RT (radiotelephone) mode. Press the RT/CH
key to show the RT screen.
2.1 Choosing Class of Emission
There are three emission modes, SSB, TLX and AM.
•SSB: Single Sideband
•TLX: Telex (see chapter 7 to 10.)
•AM: AM (You cannot transmit in the AM mode.)
At the radiotelephone screen, choose class of emission as follows:
1. Rotate the ENTER knob to highlight the emission mode (default: SSB) and then push the
ENTER knob. When rotating the ENTER knob clockwise, the cursor moves from “CH” to
downward.
AGC mode
SSB SIMP HIGH FAST NB SQ
SEN S
LA 10.0A
MMSI xxxxxxxxx
35 00.0000N
135 00.0000E
CH: 200
Tx: 2182.0 kHz
Rx: 2182.00 kHz
UTC 00:00
EPFS 23:59
SEN
LA
Emission mode
TLX
AM
SSB
POS
2. Rotate the ENTER knob to choose mode desired and then push the ENTER knob.
AGC is automatically selected according to emission mode.
• SSB : AGC FAST
•TLX: AGC OFF
•AM: AGC SLOW
3. However, you may change it as below .
4. Rotate the ENTER knob to choose AGC mode and then push the ENTER knob.
SSB SIMP HIGH FAST NB SQ
SEN S
IA 10.0A
MMSI xxxxxxxxx
35 00.0000N
135 00.0000E
CH: 200
Tx: 2182.0 kHz
Rx: 2182.00 kHz
UTC 00:00
EPFS 23:59
FAST
FAST
FAST
OFF
SLOW
FAST
POS
5. Rotate the ENTER knob to choose OFF, SLOW or FAST as appropriate and then push the
ENTER knob.
