10. NBDP TRANSMITTING, RECEIVING
10-2
5. Press the function key F3 again and then the 8 key to choose Manual Calling. The
following screen appears.
Mode : ARQ FEC
ID :
Manual Calling
Manual calling screen
6. Use the ← or → key to choose appropriate communication mode.
7. Press the
↓ key and input party’s ID number.
8. Press the Enter key to connect the communication line. “Channel Busy Check” appears.
If the line is free, “Connect”, “Send” and “Lock” appear in highlight as below. Further,
“HT” (High Tension) also appears when the line is connected.
Station Name :
Frequency (T/R) : 8765.00 / 8965.00(kHz) Comm Mode :ARQ
Comm Status : Connect Send Lock Error
Sending Volume : 100(%) ARQ Error : 0 ARQ Time : 0(sec)
Caps-Eng
1:File 2:Edit 3:Operate 4:Window 5:Station 6:System 7:WRU 8:HR 9:Over 10:Break
2002-09-08 2:14:28 UTC
HT
For ARQ mode, go to step 9. For FEC mode, type your message and go to step 13.
9. Press the function key F7 (WRU). The party’s answerback code appears on the screen.
Note: Step 9 and 10 are needed for ship-to-ship calling only.
10. Press the function key F8 (HR). Your ship’s answerback code is sent to the party.
11. Press the Enter key and type your message.
12. If you want to receive other party’s response, press the function key F9 (Over).
13. Press the function key F10 (Break) to disconnect the line.
