7. NBDP SYSTEM OVERVIEW
7-12
Window Color (IB-583) Chooses display colors. To change display colors:
1. Choose the option Change from Setup.
2. Press the ↓ key to choose Window Color and press the Enter
key.
Window Color Change
Window Color Setup
Default Color
To Change: ENTER To quit: ESC
3. The cursor is choosing Window Color Setup; press the Enter
key.
Window Color Setup
Window : [BASE WINDOW ]
Fore Color : [L-WHITE ]
Back Color : [BLUE ]
To Change: ENTER To Change Value: L<=>R
4. Press the → key to choose the item to change: BASE
WINDOW, BACK SCROLL, EDIT 1-2, FUNCTION, SUB MENU
1-3, MESSAGE.
5. Press the ↓ key to choose Fore Color.
6. Press the → key to choose color: L-WHITE, BLACK, BLUE,
GREEN, CYAN, RED, MAGENTA, BROWN, WHITE, GRAY,
L-BLUE, L-GREEN, L-CYAN, L-RED, L-MAGENTA, YELLOW.
7. Press the ↓ key to choose Back Color.
8. Press the → key to choose color.
9. Press the ↑ key to choose Window.
10. Repeat the step 4 to 9 to set other colors.
11. Press the Enter key followed by the Esc key.
Display Mode (IB-581) Selects display mode to normal and reverse alternately.
Self Test: Starts diagnostic test.
Function key [F7]: WRU (Who Are You?): In the ARQ mode, requests other station’s
answerback code.
Function key [F8]: HR (Here Is): In the ARQ mode, sends your ship’s answerback code.
Function key [F9]: OVER: In the ARQ mode, switches the direction of traffic; the
information receiving station becomes the information sending station, the information
sending station becomes the information receiving station.
Function key [F10]: Break: Disconnects the line.
