6. MENU OPERATION
6-3
3. Push the ENTER knob to open the user channel options window.
*** User ch entry **
MODE: SSB CH: 2-01
00201. TX: 2111.5 RX: 2111.5
00202. TX: 2222.0 RX: 2222.0
00203. TX: 2333.5 RX: 2333.5
00204. TX: 2444.0 RX: 2444.0
00205. TX: 2555.5 RX: 2555.5
MODE
CH
FREQ
4. Rotate the ENTER knob to choose MODE and then push the ENTER knob.
*** User ch entry **
00201. TX: 2111.5 RX: 2111.5
00202. TX: 2222.0 RX: 2222.0
00203. TX: 2333.5 RX: 2333.5
00204. TX: 2444.0 RX: 2444.0
00205. TX: 2555.5 RX: 2555.5
SSB
NBDP
DSC
CW
MODE: CH: 2-01
5. Rotate the ENTER knob to choose appropriate mode among SSB, NBDP and DSC and
then push the ENTER knob.
*** User ch entry **
MODE: SSB
00201. TX: 2101.5 RX: 2101.5
00202. TX: 2202.0 RX: 2202.0
00203. TX: 2303.5 RX: 2303.5
00204. TX: 2404.0 RX: 2404.0
00205. TX: 2505.5 RX: 2505.5
CH : 2-01
C H : 0 − 0 0
- 256 channels may be registered.
- Band no. setting range is 1-29 and band channel no. range is
01-99.
- For DSC, four channels can be registered per band (2, 4, 6
8, 12, 16, 18, 22, 25).
6. Key in channel no. and then push the ENTER knob. For example, press 0, 1, 2, 3, 4 and
then push the ENTER knob to enter channel 01234.
** User ch entry **
MODE : SSB
01234. TX: 0.0 RX: 0.0
01240. TX: 12666.0 RX: 13666.0
01241. TX: 12777.5 RX: 13777.5
01242. TX: 12999.5 RX: 13999.5
01250. TX: 12100.0 RX: 13100.0
CH : 12-34
TX : 0.0 kHz
RX : 0.0 kHz
7. Enter TX frequency with the numeric keys.
8. Rotate the ENTER knob to choose RX.
9. Enter RX frequency with the numeric keys and then push the ENTER knob.
10. Rotate the ENTER knob to display all channels entered.
11. Press the CANCEL key twice.
