10. NBDP TRANSMITTING, RECEIVING
10-6
10.5 Communication Example
Call the coast station following the procedure in paragraph 10.2. Then, communicate with
the coast station. Below is a communication example.
12345 KOBE X
1480 HKRDO VRX
MOM
GA+?
OPR+
MOM
1480 HKRDO VRX
12345 KOBE X
KOBE DE HKRDO GOOD MORNING
NW NIL QRV GA+?
GM NW QTC1+?
QRV K GA+?
TOR
Teleprinting Over Radio
(Message TX starts.)
Msg No.
KOBE DE HKRDO QSL NR9004
TKS NW NIL +?
TKS NW NIL BIBI +?
TKS SEE YOU LATER
BIBI
KKKK QSL +?
End message.
NR 9004
TO: TELEX 1234567 FURUNO
JAPAN OFFICE
INT. DEP. SEC-1 MANAGER
FM: KOBE MARU/12345 KOBE X
TEXT: Type message.
If this is your first
communications with a
particular coast station,
the coast station asks
for you selcall no. ship
name, call sign and
AAIC (your enterprises
name for which to
charge to charge toll
call. That registers you
with the coast station.
Thereafter, if your
answerback code is
correct automatic
transmission is possible.
Coast station disconnects the line.
Selcall No. Ship name or call sign
Own answerback code
Automatically sent from Coast
station (ex. Hong Kong)
Type at your side
(GM=Good Morning. I have
a message for you.)
Receiver: Telex no.1234567
FURUNO ELEC. CO.
Sende: KOBE MARU
Type message
Message finished. Can you
acknowledge receipt)
From coast station
From HKRD0 to KOBE.
Received NR9004. Thank you.
No more to send.
Type at your ship
(Thank you. I have nothing to
send. Bye Bye.
From coast station
Thank you. See you later.)
From coast station.
(Send your message.)
Type at your side
(To send a message file, type
MOM before TOR and wait
awhile.)
Type at your side within 30 s.
(Call operator manually.)
Message from coast station
(
Wait. From HKRDO to KOBE.
Nothing to send. Do you
have anything to send?)
Call completed,
To send message
to ship
connected with
coast station
Communications example
