List of Replaceable Parts
Parts Lists
8
8-31
Table 8-8. A6 High Voltage Sense PCA
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
C98,C99 CAP,CER,470PF,+-10%,50V,C0G 733071 2
C100,C121 CAP,POLYCA,1UF,+-10%,50V 271619 2
C101,C103,C106,
C107,C109,C111,
C114,C115 C117-
119,C124,C125,
C150-152,C154,
C157,C163,C166,
C167,C169-176,
C181-183
CAP,POLYES,0.1UF,+-10%,50V 649913
649913
649913
649913
649913
649913
649913
649913
32
C102 CAP,POLYCA,0.15UF,+-5%,50V 343616 1
C104,C127 CAP,CER,680PF,+-5%,50V,C0G 743351 2
C105 CAP,PORC,1.0PF,+-0.25PF,1000V 603571 1
C108 CAP,CER,10PF,+-2%,50V,C0G 713875 1
C110,C112,C122,
C123,C177
CAP,TA,10UF,+-20%,35V 816512
816512
5
C113,C128 CAP,CER,100PF,+-5%,50V,C0G 831495 2
C120 CAP,POLYES,0.1UF,+-10%,50V 649913 1
C153 CAP,CER,3300PF,+-5%,50V,C0G 830612 1
C155 CAP,POLYES,0.01UF,+-10%,50V 715037 1
C156,C158-161 CAP,AL,22UF,+-20%,35V 817056 5
C162,C164,C165,
C168
CAP,CER,39PF,+-2%,50V,C0G 714840
714840
4
C180 CAP,POLYES,0.47UF,+-10%,50V 697409 1
C401 CAP,AL,600UF,+75-10%,15V,SOLV 557660 1
C402 CAP,AL,47UF,+-20%,50V,SOLV PRO 822403 1
C403 CAP,CER,0.22UF,+80-20%,50V,Z5U 649939 1
CR100,CR103,
CR104,CR150-153
*
*
DIODE,SI,BV=75V,IO=150MA,500MW 659516
659516
7
CR101,CR102 * DIODE,SI,BV=20V,IO=50MA,250MW 836288 2
CR105-108 * DIODE,SI,BV=35V, LOW LEAKAGE 723817 4
CR401-404 DIODE,SI,400 PIV,1 AMP 831586 4
CR405 * DIODE,SI,BV=75V,IO=150MA,500MW 203323 1
E105 SOCKET,SINGLE,SOLDER,FOR .064 851287 1
E155 TERM,FASTON,TAB,.110,SOLDER 512889 1
H27 GROUND STRIP,BECU,SPRING FINGE 370619 1
H108 RIVET,S-TUB,OVAL,AL,.087,.250 838482 2
H110 RIVET,S-TUB,OVAL,STL,.118,.281 650283 2
H121 RIVET,POP,DOME,AL,.125,.316 807347 4
H126 LABEL,C-MOS INSTRUCTION 464016 1
J102 CONN,DIN41612,TYPE R,64 PIN 782094 1
J118-124 SOCKET,SINGLE,SOLDER,FOR .021 851290 7
J152 CONN,COAX,SMB(M),PWB 352450 1
J401 CONN,MATE-N-LOK,HEADER,4 PIN 512269 1
J402 HEADER,1 ROW,.156CTR,12 PIN 831354 1
