List of Replaceable Parts
Parts Lists
8
8-21
Table 8-5. A3 High Voltage Amplifier PCA
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
C601 CAP,POLYES,1UF,+-10%,50V 733089 1
C602 CAP,CER,100PF,+-5%,50V,C0G 831495 1
C603,C606,C609-
611,C620
CAP,AL,10UF,+-20%,63V,SOLV PRO 816843
816843
6
C604,C605 CAP,CER,1.5PF,+-0.25PF,1000V,C 836346 2
C607,C614,C654,
C662
CAP,CER,22PF,+-10%,1000V,C0G 817023
817023
4
C608,C612,C619,
C655,C656,C658,
C659,C665,C666,
C668
CAP,POLYES,0.1UF,+-10%,50V 649913
649913
649913
649913
10
C613 CAP,CER,3.3PF,+0.25PF,100V,C0J 816678 1
C615,C621,C622,
C652,C657
CAP,POLYES,0.01UF,+-10%,50V 715037
715037
5
C616 CAP,POLYES,0.001UF,+-10%,50V 720938 1
C617 CAP,AL,1UF,+-20%,50V 782805 1
C618 CAP,AL,2.2UF,+-20%,50V 769687 1
C651,C664,C667 CAP,CER,0.005UF,+-20%,3000V,Z5 188003 3
C653 CAP,CER,10PF,+-10%,3000V,C0G 817049 1
C660,C661 CAP,CER,39PF,+-5%,1000V,C0G 817031 2
C663 CAP,CER,0.01UF,+100-0%,1600V,Z 106930 1
CR602-605,
CR607-612,
CR651,CR653,
CR655, CR658,
CR659
*
*
*
*
DIODE,SI,BV=75V,IO=150MA,500MW 203323
203323
203323
203323
15
CR652,CR654,
CR656,CR657
DIODE,SI,1K PIV,1.0 AMP 707075
707075
4
H601 RIVET,S-TUB,OVAL,AL,.087,.250 838482 2
H603 RIVET,POP,DOME,AL,.125,.316 807347 4
H626 LABEL,C-MOS INSTRUCTION 464016 1
J603 HEADER,1 ROW,.100CTR,2 PIN 602698 1
J604 HEADER,1 ROW,.156CTR,10 PIN 446724 1
J605,J661-664 HEADER,1 ROW,.156CTR,8 PIN 385435 5
J653 CONN,DIN41612,TYPE 1/2R,32 PIN 836874 1
K601-604 RELAY,ARMATURE,2 FORM C,5V 733063 4
L601,L602 CHOKE, 3 TURN 452888 2
L603 INDUCTOR,2.2UH,+-5%,108MHZ,SHL 806547 1
MP28 * INSULATOR,PWR SUPPY HIGH VOLT 843102 1
MP81 CLAMP,PWB MOUNTING 823039 1
MP82 CLAMP,PWB MOUNTING 842948 1
MP601 AIDE,PCB PULL 541730 2
MP658 INSUL PT,TRANSISTOR MOUNT,DAP, 152207 3
