List of Replaceable Parts
Parts Lists
8
8-15
Table 8-3. A1 Interconnect PCA
Reference
Designator
Description
Fluke Stock
No
Tot Qty
Notes
CR1,CR13-15
*
DIODE,SI,BV=75V,IO=150MA,500MW
203323
4
H13
RIVET,S-TUB,OVAL,AL,.087,.343
838458
8
H22
RIVET,S-TUB,OVAL,STL,.118,.218
103606
4
J1
HEADER,2 ROW,.100CTR,34 PIN
836577
1
J2
HEADER,1 ROW,.156CTR,10 PIN
446724
1
J100,J103
HEADER,1 ROW,.100CTR,RT ANG,2
851667
2
K1
RELAY,ARMATURE,2 FORM C,5VDC
810911
1
K13-15
RELAY,REED,1 FORM A,5VDC
806950
3
MP1
BRACKET,RIGHT ANGLE,TAPPED,BRA
404525
4
MP5
GUIDE, HEATSINK
860205
2
P102
CONN,DIN41612,TYPE R,RT ANG,64
782102
1
P202,P351,P653
CONN,DIN41612,TYPE 1/2R,RT ANG
836882
3
TP1,TP2
JUMPER,WIRE,NONINSUL,0.200CTR
816090
2
