Fluke 5725A - Manual (Page 162)

5725A
Instruction Manual
8-22
Table 8-5. A3 High Voltage Amplifier PCA (cont)
Reference
Designator
Description
Fluke Stock
No
Tot Qty Notes
Q601 * TRANSISTOR,SI,N-JFET,TO-92 816314 1
Q602,Q603,Q606 * TRANSISTOR,SI,PNP,40V,0.35W,TO 698233 3
Q604 * TRANSISTOR,SI,N-DMOS FET,TO-72 394122 1
Q605,Q660 * TRANSISTOR,SI,NPN,SMALL SIGNAL 698225 2
Q653, Q654, Q661 HEAT SINK ASSY 665521 2
Q667, Q670 HEAT SINK ASSY 665536 2
Q657 HEAT SINK ASSY 665554 1
Q662, Q665 HEAT SINK ASSY 665528 2
Q658,Q666 * TRANSISTOR,SI,NPN,SMALL SIGNAL 346916 2
Q659 * TRANSISTOR,SI,PNP,SMALL SIGNAL 402586 1
R600 RES,WW,1.2,+-5%,2W 248658 1
R601,R609,R612,
R617,R620,R649,
R650,R659,R674,
R694,R698,R753
RES,CF,1K,+-5%,0.25W 343426
343426
343426
343426
12
R602,R603,R664,
R683,R688
RES,CF,4.7K,+-5%,0.25W 348821
348821
5
R604,R605 RES,CF,680K,+-5%,0.25W 442517 2
R606,R607 RES,MF,100K,+-1%,0.125W,100PPM 248807 2
R608 RES,MF,44.2K,+-1%,0.125W,25PPM 706317 1
R610 RES,MF,649,+-1%,0.125W,100PPM 309955 1
R611,R614 RES,MF,2K,+-0.1%,0.125W,25PPM 340174 2
R613 RES,MF,39.2K,+-0.1%,0.125W,25P 344507 1
R615 RES,MF,3.92K,+-0.1%,.125W,25PP 844662 1
R616 RES,CF,6.8K,+-5%,0.25W 368761 1
R618,R665,R675,
R690,R691,R697,
R699-701,R751,
R752
RES,CF,51,+-5%,0.25W 414540
414540
414540
414540
11
R619,R653,R655,
R656,R662,R663,
R679-681,R685,
R689,R693,R696
RES,CF,100,+-5%,0.25W 348771
348771
348771
348771
13
R621,R623,R626 RES,MF,5.49K,+-1%,0.125W,100PP 334565 3
R622 RES,MF,60.4K,+-1%,0.125W,100PP 291419 1
R624,R625 R627-
630,R632-635,
R644-646,R652
RES,CF,10K,+-5%,0.25W 348839
348839
348839
14
R631,R660,R678,
R682
RES,CF,330,+-5%,0.25W 368720
368720
4
R636 RES,MF,2K,+-1%,0.125W,100PPM 235226 1
R637 RES,CC,1.2K,+-5%,1W 109892 1
R638,R639 RES,CF,1.5M,+-5%,0.25W 349001 2
