List of replaceable parts parts lists, Table 8-4. a2 current amplifier pca (cont) – Fluke 5725A User Manual
Page 159
List of Replaceable Parts
Parts Lists
8
8-19
Table 8-4. A2 Current Amplifier PCA (cont)
Reference
Designator
Description
Fluke Stock
No
Tot Qty
Notes
R233,R237,R238,
R273
RES,MF,2K,+-1%,0.125W,100PPM
235226
235226
4
R243,R244
RES,CF,100K,+-5%,0.25W
348920
2
R247,R248
RES,MF,232,+-1%,0.125W,100PPM
289975
2
R253,R277,R282,
R283,R285,R286
RES,MF,10K,+-1%,0.125W,100PPM
168260
168260
6
R255,R267,R268
RES,CF,470K,+-5%,0.25W
342634
3
R256-259
RES,MF,1M,+-1%,0.125W,100PPM
268797
4
R260
RES,LF,5.1,+-5%,0.5W
687779
1
R261,R263, R290-
295
RES,CF,4.7K,+-5%,0.25W
348821
348821
8
R262
RES,CF,150,+-5%,0.25W
343442
1
R264
RES,CF,1K,+-5%,0.25W
343426
1
R272
SHUNT ASSY
842877
1
R276
RES,MF,9.09K,+-1%,0.125W,100PP
221663
1
R281
RES,MF,24.9K,+-1%,0.125W,100PP
291369
1
R284
RES,MF,44.2K,+-1%,0.125W,25PPM
706317
1
RT201,RT202
THERMISTOR,DISC,4.85,25C
838102
2
TP201-
205,TP207-215
JUMPER,WIRE,NONINSUL,0.200CTR
816090
816090
17
U201
*
IC,OP AMP,PRECISION,LOW NOISE
866637
1
U202
*
IC,OP AMP,PRECISION,LOW NOISE
816744
1
U203
*
IC,OP AMP,CURRENT AMP,TO-99 CA
260422
1
U204
*
IC,OP AMP,DUAL,PRECISION MATCH
782375
1
U205
*
IC,VOLT REG,ADJ,1.2 TO 37 V,1.
460410
1
U206
*
IC,VOLT REG,ADJ,NEG,-1.2VT0-37v, 1.5A
772996
1
U207
*
IC,COMPARATOR,DUAL,LO-PWR,8 PI
478354
1
U208
*
IC,OP AMP,PRECISION,LOW NOISE
782920
1
U209
*
IC,BIMOS,8 CHNL HI-VOLT DRVR W
782912
1
U210
*
IC,COMPARATOR,QUAD,14 PIN DIP
387233
1
U211
*
IC,OP AMP,QUAD,JFET INPUT,14 P
483438
1
VR201,VR202
*
ZENER,UNCOMP,6.8V,5%,20.0MA,0.
260695
2
W6
HARNESS, MFC CURRENT
843008
1
w206
ASSY, THERMISTOR
843032
1
Z201,Z203
*
RNET,MF,HERM,SIP,5700 LO V INS
809418
2
