List of Replaceable Parts
Parts Lists
8
8-29
Table 8-7. A5 Digital PCA
Reference
Designator
Description
Fluke Stock
No
Tot Qty
Notes
C501,C503-511,
C516,C518,C519,
C521
CAP,POLYES,0.1UF,+-10%,50V
649913
649913
649913
14
C502,C520
CAP,AL,22UF,+-20%,35V
817056
2
C512,C513
CAP,CER,15PF,+-20%,50V,C0G
697524
2
C514,C517
CAP,POLYES,0.33UF,+-10%,50V
715284
2
C515
CAP,TA,10UF,+-20%,35V
816512
1
C522-530
CAP,CER,470PF,+-5%,50V,C0G
830430
9
C531
CAP,CER,100PF,+-5%,50V,C0G
831495
1
CR501,CR504,
CR505
LED,GREEN,LIGHT BAR,5.0 MCD
845136
845136
3
CR502,CR506,
CR507
LED,RED,LIGHT BAR,6.0 MCD
534834
534834
3
CR508,CR509
*
DIODE,SI,SCHOTTKY,40V,DO-34
313247
2
E501
HEADER,1 ROW,.100CTR,4 PIN
417329
1
J501
SOCKET,IC,0.070 CTR,64 PIN
783688
1
J502
HEADER,2 ROW,.100CTR,RT ANG,34
836551
1
J504
SOCKET,IC,28 PIN
448217
1
J506-509
SOCKET,IC,8 PIN
478016
4
J512,J515
SOCKET,IC,24 PIN
376236
2
L501
CHOKE, 3 TURN
452888
1
MP501
PAD, ADHESIVE
735365
1
MP502
SLEEVING
142554
1
MP815
CABLE, INTERCONNECT - FRONT PA
843123
1
R501
RES,MF,1M,+-1%,0.125W,100PPM
268797
1
R502,R509
RES,CF,1K,+-5%,0.25W
343426
2
R503-507
RES,CF,47K,+-5%,0.25W
348896
5
R508
RES,MF,11.5,+-1%,0.125W,100PPM
339796
1
R510
RES,CF,10K,+-5%,0.25W
348839
1
SW502
SWITCH,PUSHBUTTON,SPST,MOMENTA
782656
1
TP501-510
JUMPER,WIRE,NONINSUL,0.200CTR
816090
10
U501,U510
*
IC,CMOS,OCTAL D TRANSPARENT LA
743294
2
U502
*
IC,CMOS,HEX INVERTERS
799924
1
U503
*
IC,CMOS,OCTL LINE DRVR W/3-ST
741892
1
U504
*
IC, 2K X 8 STAT RAM
647222
1
U505
*
IC,CMOS,QUAD INPUT NOR GATE
811158
1
U506
*
IC,CMOS,14 STAGE BINARY COUNTE
807701
1
U507
*
IC,CMOS,8-BIT MPU,2.0 MHZ,256
876326
1
U508
*
IC,VOLT SUPERVISOR,4.55V SENSE
780577
1
U509
*
IC,CMOS,DUAL MONOSTABLE MULTIB
454017
1
U511,U514
*
IC,CMOS,QUAD 2 INPUT NAND GATE
707323
2
U512
IC, NMOS, 2K X 8 EEPROM, 350 N
811075
1
U513
*
IL,CMOS,QUAD 2 INPUT AND GATE
741801
1
U515
*
EPROM,PROGRAMED 27128A-150 U51
860148
1
Y501
CRYSTAL,4.9152 MHZ,+/- 0.005%,
800367
1
Z501
RES,CERM,DIP,16 PIN,15 RES,10K
355305
1
Z502
RES,CERM,DIP,16 PIN,8 RES,24,+
806406
1
