Inverter type of data
stored in the keypad
panel

60.00

1.DATA SETTING
2.DATA CHECK
3.OPR MNTR
4.I/O CHECK

5.MAINTENANC
6.LOAD FCTR
7.ALM INF
8.ALM CAUSE
⇒9.DATA COPY

Error processing

Data check

(verify)

040HP-4
READ

040HP-4
VERIFY

Mode (data check)

040HP-4
VERIFY

Data check in progress

040HP-4
WRITE

INV RUNNING

RUN

PRG

⇒PRG

MENU
F/D

⇒LED SHIFT

040HP-4
VERIFY
COMPLETE

Data check complete

040HP-4
WRITE

1) Change disabled during operation

If a write operation is attempted during an inverter
operation, or vice versa, the error message below will
appear.
After stopping the inverter and pressing , retry the
write operation.

2) Memory error

If a write operation is attempted while data has not been
saved (i.e., no data) in the keypad panel data memory
during the read mode, the following error message will
appear:

WRITE

MEMORY ERROR

3) Verify error

During a data check (verify) operation, if data stored in
the keypad panel differs from data stored in the inverter,
the following error message is displayed to indicate the
function No. The data check is suspended.
To continue the data check and check for other
mismatching data, press . To stop the data check
and switch to another operation, press .

075HP-4
WRITE

ERR:F25

4) Data protection

When WRITE to the inverter which is protected by
"Data protection" function, the following error message
will appear. After released the protection, write
operation is attempted.

040HP-4
WRITE

DATA PRTCTD

FUNC
DATA

RESET

PRG

∧

RESET
