CONNECTIONS

SETUP

ADV

ANCED

OPERA

TION

REMOTE

CONTROLLER

TROUBLESHOOTING

OTHERS

NAMES AND

FUNCTION

BASIC

OPERA

TION

ENGLISH

Dolby MODE

(Dolby Digital, Pro Logic

x MOVIE, Pro Logic

MUSIC, Pro Logic

x GAME)

This mode is used with source materials encoded in
Dolby Digital and Dolby Surround.

DOLBY DIGITAL
This mode is enabled when playing source materials
encoded in Dolby Digital.
Playing multichannel-encoded 5.1 channel Dolby
Digital sources provides 5 main audio channels (left,
center, right, surround left and surround right) and a
Low Frequency Effect channel.
Dolby Digital EX decoding is not available in this
mode.

Dolby Pro Logic

x has 5 modes:

Pro Logic

x MOVIE

This mode provides 6.1 or 7.1 channel surround
sound from Dolby Surround, encoded stereo movie
soundtracks.
Pro Logic

x MUSIC

This mode provides 6.1 or 7.1 channel surround
sound from conventional stereo sources (analog or
digital), such as CD, tape, FM, TV, stereo VCR, etc.
Pro Logic

x GAME

This mode restores the impact low-frequency
surround effects by routing them to the system’s
subwoofer.
5.1ch + Pro Logic

x Movie

This mode provides 7.1 channel surround sound from
5.1 channel sources movie soundtracks.
5.1ch + Pro Logic

x Music

This mode provides 6.1 or 7.1 channel surround sound
from 5.1 channel sources music soundtracks.

Notes:

• Pro Logic IIx mode will decode as Pro Logic II

mode when the SURR. B is set to “NONE” from
SPEAKER SETUP menu. (See page 30)

• Pro Logic IIx mode is available for a 2 channel input

signal which is encoded in Dolby Digital, HDCD or
PCM format.

dts

dts, Neo:6 Cinema, Neo:6 Music
This mode is for DTS-encoded source materials
such as laserdisc, CD and DVD. Neo:6 is for some 2
channel sources.

dts
This mode is enabled when playing source materials
encoded in dts multichannel.
Playing multichannel encoded-5.1 channel dts
sources provides five main audio channels (left,
center, right, surround left and surround right) and a
Low Frequency Effects channel.
dts-ES decoding is not available in this mode.
The DTS mode cannot be used when an analog
input has been selected.

Neo:6 Cinema, Neo:6 Music
This mode decodes 2 channel signals into 6 channel
signals using high-accuracy digital matrix technology.
The DTS Neo:6 decoder has near-discrete properties
in the frequency characteristics of the channels as
well as in channel separation.
According to the signals to be played back, DTS Neo:6
uses either the Neo:6 Cinema mode optimized for
movie playback or the Neo:6 Music mode optimized
for music playback.

Note:

• The Neo:6 mode is available for 2 channel input

signals which are encoded in Dolby Digital, HDCD
or PCM format.

CIRCLE SURROUND II
(CSII-CINEMA, CSII-MUSIC, CSII-MONO)

Circle Surround is designed to enable multichannel
surround sound playback of non-encoded and
multichannel encoded material.
Backward compatibility provides listeners with up to
6.1 channels of surround performance from an entire
collection of music and fi lm, including broadcast,
videotape and stereo recorded music.
Depending on source material, you can select CS

Cinema mode, CS

-Music mode or CS

-Mono

mode.

Note:

• The CS II mode is available for 2 channel input

signals which are encoded in Dolby Digital, HDCD
or PCM format.

AUTO

When this mode is selected, the unit determines
whether the digital input signal is Dolby Digital,
Dolby Digital Surround EX, Dolby Digital Plus, Dolby
TrueHD, DTS-HD, DTS, DTS-ES, DTS 96/24 or PCM
audio.
Surround EX & DTS-ES will operate for multichannel
sources that have a Dolby Digital Surround EX or
DTS-ES auto trigger fl ag in the digital signal.
When a Dolby Digital or DTS signal is input, the
number of channels for which the corresponding
signal is encoded will be played.
Inputting a Dolby Digital two channel signal with
Dolby surround status automatically subjects that
signal to Pro Logic

x movie processing before play.

PCM 96 kHz source material can be played in this
mode.

Notes:

• When you use this mode with certain DVD and CD

players, performing operations such as skip or stop
may momentarily interrupt the output.

• When the signal is not decoded, the mode is changed

to AUTO mode automatically. See page 41 to
confi rm the available decoding modes.

SOURCE DIRECT

In the Source Direct mode, the tone control circuit
Acoustic EQ. and bass management confi guration
are bypassed for full-range frequency response and
the purist audio reproduction.

Notes:

• Speaker size is set to Front L/R = LARGE, Center =

LARGE, Surround L/R = LARGE and Subwoofer
= YES automatically. Tone controls, equalizer and
additional processing are deactivated.

• When you use this mode with certain DVD and CD

players, performing operations such as skip or stop
may momentarily interrupt the output.

• In SOURCE DIRECT mode, ACOUSTIC EQ and

M-DAX are not available.

PURE DIRECT

The Pure Direct mode further reduces sources of
noise in addition to effect of the Source Direct mode,
by blocking output from the video jacks (VIDEO,
S-VIDEO, COMPONENT VIDEO and HDMI) and
turning the FL display off.

Note:

• In PURE DIRECT mode, ACOUSTIC EQ and M-

DAX are not available.

EX/ES

This mode provides 6.1 channel surround for Dolby
Digital EX, and DTS-ES-encoded source material
such as DVD.
This mode cannot be used when an analog input has
been selected.

Dolby Digital EX
In a movie theater, fi lm soundtracks that have been
encoded with Dolby Digital Surround EX technology
are able to reproduce an extra channel which has
been added during the mixing of the program.
This channel, called surround back, places sounds
behind the listener in addition to the currently
available front left, front center, front right, surround
right, surround left and subwoofer channels.
This additional channel provides the opportunity
for more detailed imaging behind the listener and
brings more depth, spacious ambience and sound
localization than ever before.
Dolby Digital EX is not available in systems that do
not have without surround back speaker(s).

DTS-ES (Discrete 6.1, Matrix 6.1)
DTS-ES adds the surround center channel audio to
the DTS 5.1 channel format to improve the acoustic
positioning, and makes acoustic image movement
more natural with the 6.1 channel reproduction.
This unit incorporates a DTS-ES-decoder, which
can handle DTS-ES Discrete-encoded and DTS-ES
Matrix-encoded program sources from DVD, etc.
DTS-ES Discrete 6.1 features digital discrete
recording of all channels, including the surround back
channel(s), and higher quality audio reproduction.
DTS-ES is not available in systems that do not have
surround back speakers.
