6-2 CHECK AUTO

These menus are for confirming the results of
AUTO SETUP function equalizer measurement
(AUDYSSEY, FRONT, FLAT).

Select

“6. ACOUSTIC EQ” from MAIN MENU

with the

cursor buttons and press the

ENTER button.

Select

“CHECK AUTO” with the

cursor

buttons.

Press the ENTER button to enter the

selection.

C H E C K A U T O
M D :

A U D Y S S E Y

6 3 0 . 0

C H : F L 1 2 5 0 . 0
2 5 0 0 . 0
5 0 0 0 . 0
1 k 0 . 0
2 k 0 . 0
4 k 0 . 0
8 k 0 . 0
1 6 k 0 . 0

R E T U R N

E X I T

125 500

250 1k

16k

0dB

-20

Select MD (mode) with the

cursor buttons

followed by the desired equalizer (“AUDYSSEY”,
“FRONT”, “FLAT”).

CH:

Select the channel to check with the

cursor

buttons.

Notes:

• The frequency will not be exactly the same as in the

Preset G. EQ modes.

• FL and FR are not indicated on the CHECK AUTO

2 menu.

Once

fi nished checking, select “RETURN” with

the

cursor buttons and press the ENTER

button to return to the “6. ACOUSTIC EQ”
menu.

6-1 PRESET G. EQ ADJ

These modes allow you to set a 9-band graphic
equalizer for each of the 7 channels.

Select

“6. ACOUSTIC EQ” from MAIN MENU

with the

cursor buttons and press the

ENTER button.

Select

“PRESET G. EQ ADJ” with the

cursor buttons.

Press the ENTER button to enter the

selection.

125 500

250 1k

16k

P R E S E T A D J U S T
R E S E T :

C H

6 3 0 . 0

C H : F L 1 2 5 0 . 0
2 5 0 0 . 0
5 0 0 0 . 0
1 k 0 . 0
2 k 0 . 0
4 k 0 . 0
8 k 0 . 0
1 6 k 0 . 0

R E T U R N

E X I T

0dB

-20

RESET:

Using the

cursor buttons, select the

channel(s) to be reset to either the currently
displayed channel (“CH”) or all channels (“ALL”),
and press the ENTER button to enter the setting.
“ALL” : Resets all channels.
“CH” : Resets only the currently displayed

channel.

CH:

Select the channel (“FL”, “C”, “FR”, “SR”, “SBR”,
“SBL” or “SL”) to adjust with the

cursor

buttons, and switch to the adjustment mode with
the

cursor button.

Frequency:

Select the target frequency on the graph with the

cursor buttons and press the ENTER button

to enter the selection. Adjust the level with the

cursor buttons. (Note that this can be adjusted

to any level between –20 and +9 dB in 0.5 dB
increments.)
Move to the next frequency with the

cursor

buttons, and adjust the level.

After you complete this portion of the setup, press
the ENTER button to enter the settings. Move cursor
to “RETURN” with the

cursor buttons and press

the ENTER button.

7 NETWORK SETUP

These settings relate to playing music, photos, and
movie fi les stored on a network device connected
to this unit.

Select “7. NETWORK SETUP” on the MAIN

MENU using the cursor buttons

7 . N E T W O R K S E T U P

V I D E O :

N T S C

R E S O L U T I O N : 4 8 0 / / 5 7 6 i

S C R E E N S A V E R : O N

R E T U R N

N E X T

E X I T

Select the menu you want to set using the

cursor buttons

, and press ENTER.

• RESOLUTION:
Use the

cursor buttons to select video signal

resolution (pixel count) on the NETWORK PLAYER
from the following options.
“480/576i”

↔

“480/576p”

↔

“720p”

↔

“1080i”

↔

“AUTO”

↔

“480/576i”

AUTO:

Sets an appropriate resolution for a television that
is connected using HDMI.
(If the unit is not connected to the television using
HDMI, the output is 480i/576i)
(If connected by converting to DVI, the output is
480p/576p)

480i/576i:

The output is 480i/576i.

480p/576p:

The output is 480p/576p.

720p:

The output is 720p.

1080i:

The output is 1080i.

Notes:

• If a monitor connected using HDMI is changed

during the AUTO setting, the screen returns
automatically to the top menu and the resolution is
changed to one that is appropriate for the monitor. If
a dialog box or the TOOL menu is displayed at this
time, the resolution is changed after the dialog box
or TOOL menu is closed.

• Set 480i/576i if you are using VIDEO/S-VIDEO

output.

• If you are using a monitor connected using HDMI,

and the signal is being input from the network, the
video signal is output in the resolution that was set
in RESOLUTION.

• SCREEN SAVER:
Use the

cursor buttons to select “ON” or “OFF”

for the screen saver from the video signal that is
output from the unit.

ON:

If no operation is made for 10 minutes on the
NETWORK screen or SETTING screen, the
screen saver is activated on the monitor. (The
screen goes dark)

OFF:

The screen saver is not activated even if no
operation is made for 10 minutes.

Notes:

• The screen saver is not activated during photo

display or video playback.

• This setting can only be changed when the

NETWORK function of this unit is selected.
