33
ENGLISH
SUB W LEVEL:
Set the effect level of the subwoofer speaker
between –18 and +12 level in 0.5 level interval .
• If “NONE” was selected for the subwoofer speaker
setting in the SPEAKER SIZE, then this setting will
not appear.
Note:
• Setting to a mode other than multichannel stereo or
CSII will affect the speaker level as explained in “2-2
MANUAL SETUP”.
After you complete this portion of the setup, move the
cursor to “RETURN” with the
3 , 4 , 1 and 2 cursor
buttons and press the ENTER button to go to the 3.
SURR SETUP menu.
3-4 NEO:6 PARAMETER
The DTS NEO:6 mode enables a maximum 6.1
channel output with just 2 channel input. (It also
supports 5.1 channel input.)
This mode expands the sound image from the center
channel.
1. Select “3. SURROUND SETUP” from MAIN
MENU with the 3 or 4 cursor buttons and press
the ENTER button.
2. Select “NEO:6 PARAMETER” with the 3 or 4
cursor buttons.
3. Press the ENTER button to enter the
selection.
N E O : 6 P A R A M E T E R
C E N T E R G A I N : 0 . 3
R E T U R N N E X T E X I T
4. Set the CENTER GAIN level between 0.0 and
1.0 in 0.1 level increments with the 1 or 2 cursor
buttons.
After you complete this portion of the setup, move
cursor to “RETURN” with the
3 , 4 cursor buttons and
press the ENTER button.
Notes:
• This parameter can only be set in the NEO:6-Music
mode.
• If “NONE” was selected for the center speaker
setting in the SPEAKER SIZE menu, this setting is
disabled.
3-2 PL II x (PRO LOGIC II x) MUSIC PARAMETER
Pro Logic II x-Music mode creates a rich and
enveloping surround ambience from stereo sources
such as CDs.
In this mode, this unit includes three controls to fi ne-
tune the sound fi eld as follows.
1. Select “3. SURR SETUP” in MAIN MENU with
3 or 4 cursor buttons and press the ENTER
button.
2. Select “PL II x MUSIC PARAMETER” with the 3
or 4 cursor buttons.
3. Press the ENTER button to enter the
selection.
P L x M U S I C P A R A M E T E R
P A R A M E T E R : D E F A U L T
P A N O R A M A : O F F
D I M E N S I O N : 0
C E N T E R W I D T H : 3
R E T U R N N E X T E X I T
PARAMETER:
Select “DEFAULT” or “CUSTOM” with the 1 or 2
cursor buttons.
If you select “CUSTOM”, you can adjust three
parameters as listed below.
PANORAMA:
Select the PANORAMA mode “ON” or “OFF” with
the
1 or 2 cursor buttons.
Panorama wraps the sound of the front left and right
speakers around you, for an exciting perspective.
DIMENSION:
Set the DIMENSION level between –3 and +3 level
in 1 level intervals with the
1 or 2 cursor buttons.
Adjust the sound fi eld either towards the front or
towards the rear.
This can be useful to help achieve a more
suitable balance from all the speakers with certain
recordings.
CENTER WIDTH:
Set the CENTER WIDTH level between 0 and 7 in
1 level intervals with the
1 or 2 cursor buttons.
Center width allows you to gradually spread the
center channel sound into the front left and right
speakers.
At its widest setting, all the sound from the center
is mixed into the left and right speakers.
This control may help achieve a more spacious
sound or a better blend for the front image.
If “NONE” was selected for the center speaker
setting in the SPEAKER SIZE menu, this setting
cannot be selected.
After you complete this portion of the setup, move
cursor to “RETURN” with the
3 , 4 , 1 and 2 cursor
buttons and press the ENTER button.
3-3 CS II PARAMETER
1. Select “3. SURROUND SETUP” from MAIN
MENU with the 3 or 4 cursor buttons and press
the ENTER button.
2. Select “CS II PARAMETER” with the 3 or 4
cursor buttons.
3. Press the ENTER button to enter the
selection.
C S P A R A M E T E R
T R U B A S S : 0
S R S D I A L O G : 0
R E T U R N N E X T E X I T
TRUBASS:
Set the TRUBASS level between 0 and 6 in 1- level
increments with the
1 or 2 cursor buttons.
TRUBASS produced by the speakers are an octave
below the actual physical capabilities of the speakers
adding exciting, deeper bass effects.
SRS DIALOG:
Set the SRS DIALOG level between 0 and 6 in 1-
increments with the
1 or 2 cursor buttons.
This can be popped out of the surround audio
effects, allowing the listener to easily discern what
the actors say.
If “NONE” was selected for the center speaker
setting in the SPEAKER SIZE menu, this setting
cannot be selected.
After you complete this portion of the setup, move
cursor to “RETURN” with the
3 , 4 , 1 and 2 cursor
buttons and press the ENTER button.
Note:
• This parameter can only be set in the CSII mode.
