Page 8
CAN2-002 Install & Operating Instructions
8
© 2014 Lingenfelter Performance Engineering
1.3
Parts List
#
Description
Item ID/PN
1
CAN to analog module
CAN2-002
1
CAN2-002 mating harness, 12 wire x 12"
L480390004
12
0.35 - 0.50 mm^2 male terminal (20-22AWG)
15326268
12
20-22AWG white seal
15366021
12
Cavity plug, green
15305171
1
6 foot USB 2.0 cable, 6', A Male to Mini-B
MONO-8634
2
Hook and loop tape, per inch
06483
2
Self tapping screw
AV16037
1
USB flash drive with CAN2 software
1
LPE 9" decal
L920010000
1
Installation instructions
