Output signal related items, Output signal related item s – Lingenfelter L460260704 Lingenfelter CAN to Analog Gauge & Relay Output Module CAN2 v1.0 User Manual
Page 53
Using the software
53
© 2014 Lingenfelter Performance Engineering
4.2.5
Output Signal Related Items
The lower half of main software window represents primarily output signal related items.
These items are:
Gauge Presents
Function
Output Settings
Output Type
Data Table
Set Breakpoints (doesn't exist for relay outputs or Voltage Out)
Start Calibrate Gauge (doesn't exist for relay outputs or Voltage Out)
