Lingenfelter L460260704 Lingenfelter CAN to Analog Gauge & Relay Output Module CAN2 v1.0 User Manual
Page 40
CAN2-002 Install & Operating Instructions
40
© 2014 Lingenfelter Performance Engineering
If you want to connect to the CAN2 module and read the existing data from the module, go to the
Communications menu and select Connect:
The CAN2 software will then connect to the CAN2-002 module and read the existing configuration from
the module. The software will then show the gauge adjustment settings for Output1 and will change to
"Auto Retrieved File" in brackets after the software Version as shown:
