1.2 Features & Benefits
Features:
Can be used to retransmit and display almost any data on the vehicle data network.
Can be used to control most analog OEM and aftermarket electronic gauges including temperature,
pressure, tachometer and speedometer
Four outputs
o Multiple units can be used at once for additional outputs
Provides programmable relay activation output
o Relay output can be based off of one variable or a combination of two variables.
o When based on two system variables, the output status can be either AND or OR for the two
variables
Examples
Turn fans on when coolant temperature is above 190 degrees AND vehicle speed is
below 50 mph
Turn on warning indicator when engine RPM is above 1500 RPM AND oil pressure is
below 30 PSI
Can be used to provide a 0-5 volt analog output for almost any CAN variable on the vehicle
o Send ECM sensor data to your engine dynamometer data acquisition system
Software includes a database of common CAN messages
o GMLAN
For use with most newer GM vehicles and crate engines
o J1939 messages
For use with many newer heavy duty truck, bus, marine and off-road equipment applications
o More CAN messages for other OEM and aftermarket applications to be added over time
Software allows users with knowledge of CAN information to configure almost any CAN message as
an output
Pre-configured outputs for common gauges
o Database of common gauge calibrations built into the software
o Additional gauge calibrations to be added over time
Benefits:
Simplifies wiring
Allows newer engines to be installed in older vehicles and retain the factory original or aftermarket
gauges
No additional sensors needed for many applications
Reduces cost
