DT 200 Users Manual version 1.E Diagnostic Tests
31
Function 64 Configure Passwords
Use function 64 to enter password data. The DT200 provides two security passwords
that can be activated and entered to protect configuration data. Password 1 is used to
protect I/O port configuration, setpoint, and event monitor data. Password 2 is used to
protect calibration and scale configuration data. Security level 3 provides extra
protection for password level 2 data. Security level 3 requires the entry of password 2
and the Function Lock inside the DT200 to be in the unlocked position. Password 3 will
inhibit viewing, changing, and uploading of Scale Basic functions to a PC when
password is active but will allow downloading a new Scale Basic program from the PC to
the indicator. All passwords will be disabled once the new program has been downloaded
into the indicator and should be reactivated.
The Operation Parameter Reference Table lists the configuration parameters and the
password/security level required to access them. The DT200 prompts “PASS 1” when a
parameter is selected that requires password level 1. If the entered password is incorrect,
the DT200 displays “Error”. Press the ENTER key to try again. Press the CLEAR to
exit from password entry.
IMPORTANT NOTE: Write down the passwords and put them in a safe place. If you
loose and forget a password, there is no way to access the protected functions.
1. Hold the CLEAR key down and press the ENTER key to enter the configure mode.
2. Enter CFG 64. The DT200 prompts “P1 xxxx” where xxxx is the current password
number. Enter a new password number or press the ENTER key to use the displayed
number. Enter a 0 (zero) for the password number to disable the password.
3. The DT200 prompts “P2 xxxx”. Enter password 2 data.
4. The DT200 prompts “P3 xxxx”. Enter password 3 data.
Function 65 Configure Print Formats
Use function 65 to modify print formats to meet your print requirements. The print
formats are grouped into PAGES that are used for generating print data onto a form.
Each page is organized into rows and columns as follows:
Line No. Column No. Item No.
Line No. = Line number on the page to print the item on.
Column No. = Column position where item print begins.
Item No. = Item to print.
Print format design requires you to become familiar with the PAGE LIST and the PRINT
ITEM LIST. The PAGE LIST describes how each PAGE is used. The PRINT ITEM
LIST describes what ITEMS can be included in each page. Use the print format
worksheets to design new print formats. The PRINT FORMAT DESIGN EXAMPLE
illustrates how a print format is designed. A list of the default print formats is found in
