Page 34
6: Line and Tunnel Settings
XPort Pro User Guide
34
4.
Enter or modify the following settings:
Table 6-3
Line Configuration
5.
Click Submit.
6.
Repeat above steps as desired, according to additional line(s) available on your product.
Line - Configuration
Settings
Description
Name
If the Terminal Login Menu feature is being used, enter the name for the
line. Leaving this field blank will disable this line from appearing in the
Terminal Login Menu. The default Name is blank. See
for related configuration information.
Interface
Select the interface type from the drop-down menu. The default is RS232.
Note:
This option is only supported in XPort Pro, EDS4100, EDS1100 and
EDS2100.
State
Indicates whether the current line is enabled. To change the status, select
Enabled or Disabled from the drop-down menu.
Protocol
Select the protocol from the drop-down menu. The default is Tunnel.
Baud Rate
Select the baud rate from the drop-down menu. The default is 9600.
Parity
Select the parity from the drop-down menu. The default is None.
Data Bits
Select the number of data bits from the drop-down menu. The default is 8.
Stop Bits
Select the number of stop bits from the drop-down menu. The default is 1.
Flow Control
Select the flow control from the drop-down menu. The default is None.
Xon Char
Specify the character to use to start the flow of data when Flow Control is
set to Software. Prefix a decimal character with \ or a hexadecimal
character with 0x, or provide a single printable character. The default Xon
char is 0x11.
Xoff Char
Specify the character to use to stop the flow of data when Flow Control is
set to Software. Prefix a decimal character with \ or a hexadecimal
character with 0x, or provide a single printable character. The default Xoff
char is 0x13.
Gap Timer
The driver forwards received serial bytes after the Gap Timer delay from
the last character received. By default, the delay is four character periods at
the current baud rate (minimum 1 ms).
Threshold
The driver will also forward received characters after Threshold bytes have
been received.
