D1.4 IPB-RIO-C-80MM
Similar to the -SHORT version, this transition module extends the signals shown in table D1.3 to a
rear panel. Naturally, not all enclosures are suitable for this type of connection and the following
must be considered.
{
Inova Desktop systems have an integrated fan - will the transition module interfere with it?
{
84HP Inova CoolBreeze systems are too short to accept an 80mm transition module.
{
Inova Industrial enclosures are available in 2 standard configurations:
{
Wall Mounting
{
Rack Mounting
{
Wall mounted racks are not suitable for rear I/O
{
The Inova rack mounted industrial enclosure must be delivered without rear panelling as
the
position of the transition module will vary depending on the chosen enclosure and
backplane.
Figure D1.4 IPB-RIO-C-80MM
