©2002 Inova Computers GmbH Page 3-11 Doc. PD00581013.004
ICP-PIII Interfaces
CompactPCI
®
3
Z A B C D E F Z A B C D E F Z A B C D E F Z A B C D E F Z A B C D E F Z A B C D E F Z A B C D E F Z A B C D E F
Figure 3.10 Inova’s 32-Bit CompactPCI 8-Slot Backplane - RH System Slot
Note:
The logical slots are different to the
physical slots. The slot marked with the
‘
̅‘ is the System Slot and always as-
signed logical ‘0’. The neighbouring slot
is logical ‘0xF’!
