B1.5 ICP-HDE8MS Description
As mentioned previously, the ICP-HDE8MS has a number of additional features compared to the
standard ICP-HD-1 module. These extra features include HD and FD connection with both stand-
ard connectors and the Inova flex cables. This provides the user with additional system flexibility.
Figure B1.5 Top & Bottom Views of the ICP-HDE8MS
COM1
Mouse
Keyboard
COM2
J2
J9A J10A
J18A
J1
J13A
J13 J11
J18
J10
J9
