©2002 Inova Computers GmbH Page 1-12 Doc. PD00581013.004
Product Overview ICP-PIII
Table 1.43 Continued
1.44 Front-Panel Features
Table 1.44 Front Panels
1) The physical COM2 interface is missing on Inova’s IPB-FPE8 piggyback allowing a PCI piggyback
device to be installed.
2) If this piggyback is installed the hard-disk (IDE FLASH) must be installed as stand-alone
Connector Description
J9, J10 Hard Disk Interface
J11 COM1, Keyboard and Mouse Interfaces
J13 COM2 and LPT1 Interfaces
J14 1) FLASH Extension Piggyback Connector for up to 288MBytes
J15 FireWire Interface
J16 TFT Flat-Panel, PanelLink™ or GigaSTAR Interface
J17 15-Pin High Density D-Sub VGA Graphics Interface
J18 1.4 MByte Slim-Line Floppy Drive Interface
J19 USB Interface
J20 iRDA, Reset
1) DOC FLASH greater than 288MByte may be available
Interface Description & Location
Ethernet RJ45 Connector Common to all 4TE CPU Front-Panels
FireWire Firewire Connector on 4TE CPU Front-Panel
USB USB Connector on 4TE CPU Front-Panel
VGA 15-Pin High-Density D-Sub Connector on 4TE CPU Front-Panel
Keyboard PS-2 Style on 8TE CPU Front-Panel
Mouse PS-2 Style on 8TE CPU Front-Panel
COM1 9-Pin D-Sub on 8TE CPU Front-Panel
COM2 1) 9-Pin D-Sub on 8TE CPU Front-Panel or 4/12TE CPU Extension
LPT1 25-Pin D-Sub on 4/12TE CPU Extension
PanelLink 2) 15-Pin D-Sub on 4TE CPU Front-Panel or 8TE CPU Front-Panel
GigaSTAR 2) 9-Pin D-Sub on 4TE CPU Front-Panel or 8TE CPU Front-Panel
