Page D-4

CPU Appendix-D

IPB-RIO

Appendix D

D1.3 IPB-RIO-C-SHORT

All Inova -RIO(C) compatible CPUs can take advantage of this transition module as it allows the
signals shown in table D1.3 to be recovered (used). Figure D1.3 illustrates this piggyback and
points to the available interfaces.

Figure D1.3 IPB-RIO-C-SHORT

Table D1.3 Rear I/O Type ‘C’

ETHERNET

Second Channel*

USB

Second Channel

FireWire

Second Channel

LPT 1 / FD

Yes

SPEAKER

Yes

EIDE

Yes

REAR I/O

OPTION

Rear I/O - 'C'

Note:

The Inova PIII CPU can have both

Ethernet channels routed to the front-

panel. Utilising the rear I/O option while

communicating via the second Ethernet
channel on the front-panel will result in

data conflict.
