©2002 Inova Computers GmbH

Page 3-24

Doc. PD00581013.004

Interfaces

ICP-PIII

3.35 Connecting the PIII to the ICP-FD-1

Figure 3.35 shows how the CPU connects to the slim-line floppy disk unit.

Figure 3.35 CPU to Slim-Line Floppy Disk Connection

Floppy

J11

J13

J10

J9

J4

J3

J14

J18

J6

PENTIUM III
