K EY L AMPS S ELEC S ET 500A U SER G UIDE
1-26 HCXTD840, Issue 1, July 2001
Key Lamps
About lamps Each fixed or programmable key has an associated lamp
located just above it. These include the following:
Lamp Function
Feature key lamps
(CONF, JOIN) Light when the key is activated. Answer key lamps
(answer, incoming, information, recall, or trunk
group answer) flash when a call terminates at the
key.
CAP lamps Indicate the status of their associated CAPs. For
example:
This lamp status Indicates
Dark the CAP is idle
Winking a call is on hold
Flashing a ringing call
Steadily lit an active call
