E NTERING T EST M ODE S ELEC S ET 500A U SER G UIDE
A-2 HCXTD840, Issue 1, July 2001
Entering Test Mode
Procedure 1 Flip the test switch in the direction of the arrow as
shown in
Figure A-1 .
2 Unplug the telephone line coming into the console,
then plug it back in (the telephone line plugs into the
phone at the jack labeled Line.)
Figure A-1: Attendant console control panel
3 All lamps on the console flash and the display flashes
the word TEST.
Figure A-2: Console test display
4 Make sure that all lamps are working properly.
5 Press any key under the display to proceed.
4 W 2 W T E S T L IN E R E C O U T
# # # # # # ## # # # # # # # # ##
## # # # # # # # # # # #
# # # # # # ## # # # # # # # # ##
# ## # # # # # ## #
#
# # #
#
#
# #
#
#
# #
#
#
#
#
#
#
#
## # # # # # ## # #
#
#
#
#
#
#
#
