HP ML100 - Manual (Page 36)

5. Remove the access panel (on page 7).
6. Locate the TPM connector. For more information, see the label attached to the server access panel.
CAUTION: Any attempt to remove an installed TPM from the system board breaks or
disfigures the TPM security rivet. Upon locating a broken or disfigured rivet on an installed
TPM, administrators should consider the system compromised and take appropriate measures
to ensure the integrity of the system data.
7. Install the TPM board. Press down on the connector to seat the board.
8. Install the TPM security rivet by pressing the rivet firmly into the system board.
9. Install the access panel.
10. For ML110 G6 servers, slide the server back into the rack.
11. For ML150 G6 servers, do one of the following:
o Close or install the tower bezel, as needed.
o Slide the server back into the rack.
12. Power up the server (on page 7).
Hardware options installation 36
