Model 590/592
3-22 707
Figure &
Item No.
Part No. Description Qty.
3-12 DRAIN VALVE & DRAIN SWITCH ASSEMBLIES
1 65520 DRAIN VALVE ASSEMBLY (SN: LG012JC & BELOW) 1
1 66553 DRAIN VALVE ASSEMBLY (SN: LG013JC & ABOVE) 1
2 SC01-058 SCREW #6-32 X 1 PH. PAN HD. ................................... 2
3 WA01-006 WASHER #6 TYPE A ...................................................... 2
  4
54228 DRAIN SWITCH W/BOOT ............................................ 1
5 NS02-005 NUT #6-32 HEX .............................................................. 2
6 52519 CORD ASSY., DRAIN INTERLOCK ............................. 1
7 65522 BRACKET, SWITCH (SN:AC0404025 & BELOW) ..... 1
7 67619 BRACKET, SWITCH (SN:AC0404026 & ABOVE) ...... 1
8 EF02-017 STRAIN RELIEF............................................................. 2
9 67617 BRACKET - MICROSWITCH TRIGGERING .............. 1
10* 76579 PLATE - D/I SWITCH COVER ...................................... 1

recommended part
