Model 590/592
106 3-5
Figure &
Item No. Part No. Description Qty.
3-2 ELEMENT ASSEMBLY
1 SC01-083 SCREW, (#10-32 x 1/2 PH FHD) ......................................... As Required
2 35101 SUPPORT, ELEMENT - LONG ................................ 5
3 35100 SUPPORT, ELEMENT - SHORT ............................... 5
4 SC01-074 SCREW, (#10-32 x 1/2 PH THD S) ..................................... As Required
5 35435 BRACKET, HI LIMIT PROBE .................................. 3
6 35462 BRACKET, HI LIMIT PROBE .................................. 3
  7
35234 HEAT ELEMENT ASSEMBLY, 8.5 KW 208V ......... 2
 
35598 HEAT ELEMENT, 8.5 KW 240V .............................. 2
 
48367 HEAT ELEMENT, 230 V(Int’l Only) ........................ 2
 
36290 HEAT ELEMENT, 220 V(Int’l Only) ........................ 2
8 16855 SEAL, O-RING .......................................................... 4
9 WA01-005 WASHER, (5/8 DIA. TYPE A - SERIES N) .............. 8
10 NS01-017 NUT, (5/8-18 B HEX) ................................................ 4

recommend. parts
