Model 590/592
Figure &
Item No. Part No. Description Qty.
3-4 LID & COVER ASSEMBLY
1 35792 LID INSTRUCTION LABEL ........................................... 1
2 35675 FILLER-LID...................................................................... 2
3 35243 COVER-MAIN LID .......................................................... 1
4 35413 PLATE-TRIP ..................................................................... 1
 
5 52627 PRESSURE PAD ASSY. .................................................. 2
6 49852 BUSHING-PRESSURE PAD .......................................... 2
7 SC01-204 SCREW 1/4-20X1.00 SOCK BUTT ................................. 2
8 49962 PLATE, SHIM ASSY. (L.H.) ............................................. 1
9 49890 PLATE, CAM GUIDE (L.H.)............................................ 1
10 35359 SLIDE (6”) ........................................................................ 2
11 RR01-004 RING, RETAINING ½” .................................................... 1
12 WA01-020 WASHER, LID STOP ....................................................... 1
13 51531 CAST, LID STOP .............................................................. 1
14 SC01-074 SCREW, #10-32 x ½ PH THD SS ..................................... 8
15 35223 WASHER, SPECIAL ......................................................... 1
16 35227 ROLLER, LINKAGE SHAFT .......................................... 2
17 35339 GUIDE, HANDLE SIDE .................................................. 2
18 SC01-062 SCREW, #6-32 x 3/8 PH FH ............................................. 4
20 SC01-041 SCREW, 5/16-18 x 1.00 HEX HD C ................................. 2
21 36285 WELDMENT, HANDLE TAP PLATE ............................. 1
 
23 34526 GASKET, LID - SN: AC0712021 & below ...................... 1
 
23 66620 GASKET, LID - SN: AC0712022 & above ...................... 1
24 35945 PIN, LID SUPPORT .......................................................... 1
25 52497 LATCH ASSEMBLY, COATED ....................................... 1
26 52498 LATCH SPRING ............................................................... 1
27 59169 LATCH BRACKET, LID (MACHINED) ......................... 1
28 51707 LATCH BRACKET, LID .................................................. 2
29 LW02-006 LOCKWASHER, LATCH ................................................. 2
30 SC01-248 SCREW, LATCH, 10-32 x 1.25 PH THD SS .................... 2
31 35032 PIN, LID SUPPORT .......................................................... 1
32 RR01-010 RING, RET. 3/4 SHAFT SS .............................................. 2
33 36312 WASHER, LID HINGE..................................................... 2
34 51697 PIN, LID HINGE............................................................... 1
35 49895 PLATE, CAM GUIDE (R.H.) ........................................... 1
36 49963 PLATE SHIM ASSEMBLY (R.H.) ................................... 1
37 SC01-146 SCREW, 1/4-20 x 3/4 HEX HD SS ................................... 2
38 52477 LIFT, LID .......................................................................... 1
 39
35465 CAM SLIDE FILLER ....................................................... 2
41 SC01-195 SCREW, 8-32 x 1-7/16 PH FHD S .................................... 12
42 OR01-005 O-RING, 5/16 x 1/16 DIA. ................................................ 12
43 LW01-002 LOCKWASHER, SPLIT RING 1/4 S ............................... 12
44 NS01-008 NUT, 8-32 HEX ................................................................. 12
45 79418 ASSY - 590 REBUILT LID ............................................... 1

recommended parts/* not shown
