Model 590/592
707 3-19
Figure &
Item No. Part No. Description Qty.
3-11A FILTER PUMP ASSY (SN: LG012JC & BELOW)
1 18107 CONDUIT CONNECTOR 3/8 X 90 ............................... 1
2 54484 BLOWER/PUMP – FLEXIBLE CONDUIT ................... 1
  3
17476 PUMP SEAL KIT ............................................................ 1
4 18105 ANTI SHORT 3/8 INCH ................................................. 2
5 18644 CONDUIT CONNECTOR 3/8 X 90 ............................... 1
6 51831 PUMP CONDUIT BRACKET ........................................ 1
7 55836 ASSY – OIL RETURN LINE .......................................... 1
8 16808 SLEEVE, FITTING ................................................... 2
9 16809 NUT, FITTING .......................................................... 2
10 17407 CONNECTOR, 1/2 MALE ELBOW ............................... 2
  11
67583 MOTOR – FILTER PUMP - 1/2 HP ................................ 1
12 14669 KIT - FILTER PUMP RETURN LINE ............................ 1
12 62206 ASSY - TUBE - PUMP TO DISCON - 590 .................... 1
  13
17430(use69289) UNION, MALE FITTING ............................................... 1
14 16807 FITTING, CONNECTOR MALE ................................... 1
15 FP01-122 REDUCER, 3/8 TO 1/2 ................................................... 1
16 FP02-024 NIPPLE, CLOSE 3/8 ....................................................... 1

17 35472 CHECK VALVE - PRESSURE ....................................... 1
18 FP02-007 NIPPLE 3/8 X 1-1/2......................................................... 1
19 17437 PUMP SUBASSY 5 GPM ............................................... 1
  20 17454
BODY - PUMP .......................................................... 1
  21 17456
PUMP SHIELD ......................................................... 2
  22 17451
COVER - PUMP ........................................................ 1
  23
SC01-016 PLUG 1/4 HEX COUNTERSUNK ........................... 1
  24
SC01-026 SCREW 5/16-18 X 3/4 HEX HD C ........................... 2
  25
SC01-132 1/4-20 X 5/8 SOC HD CAP SCREW ........................ 4
  26 17447
ROTOR - PUMP ........................................................ 1
  27 17446
ROLLER - TEFLON SET ......................................... 1
28 17453 PUMP O RING GASKET ......................................... 1
29* 67589 ASSY - FILTER PMP & 1/2 HP MOTOR....................... 1

recommended part
* not shown
