Heat & Glo • 6000TRS-CE • 2049-900 Rev. R • 3/13 33
Figure 31. Sealant Material
Installing the Trim
Combustible materials may be brought up to the specified clearances on the side
and top front edges of the fireplace, but MUST NEvER overlap onto the front face.
The joints between the finished wall, fireplace top and sides can only be sealed
with a 150º C minimum sealant.
Install optional marble and brass trim surround kits as desired. Marble, brass, brick,
tile, or other noncombustible materials can be used to cover up the gap between the
sheet rock and the fireplace.
Step 10 Installing Trim, Refractory, Logs, and Ember Material
1. Apply only non-
combustible facing
material to the fire-
place surround.
cauTiON
Installing the Ceramic Re-
fractory
Remove dress guard, glass
door and log package. Remove
refractory pieces from packaging
(see Figure 32). Position rear
refractory piece first and then
slide both side pieces through
the upper guide openings until
they sit firmly against the rear
of the unit. See following pages
for log installation instruction.
wARNING: CHILDREN AND ADULTS
SHOULD BE ALERTED TO THE HAZARDS
Figure 32.
TOP SEAL
JOINT
SIDE SEAL
JOINT
1,3 cm
1,3 cm
FINISH MATERIAL
MAY BE COMBUSTIBLE
- TOP AND SIDES OF UNIT
if JOiNTs beTweeN The fiNisheD walls aND
The fireplace surrOuND (TOp aND siDes)
are sealeD, a 150º c. miNimum sealaNT maTe-
rial musT be useD. These JOiNTs are NOT
reQuireD TO be sealeD. ONly NONcOmbus-
Tible maTerial (usiNG 150º c. miNimum aDhe-
sive, if NeeDeD) caN be applieD as faciNG TO
The fireplace surrOuND. see fiGure 31.
!
OF HIGH TEMPERATURES OF wORKING
SURFACES ON THESE HEATERS. wORKING
SURFACES INCLUDE ALL GLASS PANELS
AND DECORATIvE DOORS. YOUNG CHIL-
DREN SHOULD BE CAREFULLY SUPERvISED
wHEN THEY ARE IN THE SAME ROOM AS THE
APPLIANCE.
Do not obstruct or modify the
air inlet/outlet grilles. When
overlapping on both sides,
leave enough space so that the
bottom grille can be opened
and the trim door removed.
