Heat & Glo • 6000TRS-CE • 2049-900 Rev. R • 3/13 18
Figure 13. Flue with three 90° elbows
FLUE WITH THREE (3) 90° ELBOWS
MIN. 30.5 cm MAX. 61.0 cm MAX. 1.22 m
MIN. 61.0 cm MAX. 1.22 m MAX. 2.48 m
MIN. 91.4 cm MAX. 1.86 m MAX. 3.6 m
MIN. 1.22 m MAX. 2.48 m MAX. 4.9 m
H = MAX. 2.48 m MAX. 4.9 m
NOTE: v + v
1
+ H + H
1
= MAX. 10.97 m
v H H + H
1
v H H + H
1
+ H
2
MIN. 30.5 cm MAX. 61.0 cm MAX. 1.22 m
MIN. 61.0 cm MAX. 61.0 cm MAX. 2.48 m
MIN. 91.4 cm MAX. 1.22 m MAX. 3.6 m
MIN. 1.22 m MAX. 1.86 m MAX. 4.9 m
MAX. 6.1 m MAX. 1.86 m MAX. 4.9 m
FLUE WITH THREE (3) 90° ELBOWS
V
H1
V1
H1
H2
V
