Eiki LC-X71 LC-X71L - Manual (Page 71)

KE6-X7100
KE6-X71L00
-71-
Electrical Parts List
C1681 403 281 5215 CERAMIC 0.22U Z 16V
C1682 403 376 3119 ELECT 100U M 25V
C1683 403 281 5215 CERAMIC 0.22U Z 16V
C1684 403 393 0016 ELECT 470U M 25V
C1685 403 393 0016 ELECT 470U M 25V
C1701 403 376 3119 ELECT 100U M 25V
C1702 403 281 5215 CERAMIC 0.22U Z 16V
C1703 403 281 5215 CERAMIC 0.22U Z 16V
RESISTOR
R1664 401 105 0613 MT-GLAZE 10K JA 1/16W
R1665 401 190 1717 MT-GLAZE 0.000 ZA 1W
R1676 401 105 0613 MT-GLAZE 10K JA 1/16W
R1678 401 113 6416 MT-GLAZE 5.1K JA 1/16W
R1679 401 113 6416 MT-GLAZE 5.1K JA 1/16W
R1681 401 190 1717 MT-GLAZE 0.000 ZA 1W
R1684 401 105 0613 MT-GLAZE 10K JA 1/16W
R1688 401 105 0613 MT-GLAZE 10K JA 1/16W
R1689 401 105 7919 MT-GLAZE 0.000 ZA 1/16W
R1690 401 105 7919 MT-GLAZE 0.000 ZA 1/16W
COIL
L1681 645 080 6827 INDUCTOR,3.3U M
L1682 645 080 6827 INDUCTOR,3.3U M
L1683 645 080 6827 INDUCTOR,3.3U M
L1684 645 080 6827 INDUCTOR,3.3U M
L1686 645 080 6827 INDUCTOR,3.3U M
L1687 645 080 6827 INDUCTOR,3.3U M
L1688 645 080 6827 INDUCTOR,3.3U M
L1689 645 080 6827 INDUCTOR,3.3U M
MISCELLANEOUS
SC1691 645 076 3502 SURGE-ABSORBER
SC1692 645 076 3502 SURGE-ABSORBER
SC1693 645 076 3502 SURGE-ABSORBER
SC1694 645 076 3502 SURGE-ABSORBER
SW2001 610 011 2575 SLIDE SWITCH
610 307 7819 ASSY,PWB,TERMINAL1 MR3B
K2001 610 227 3793 SPEAKER TERMINAL
610 307 7826 ASSY,PWB,TERMINAL2 MR3B
K2002 610 227 3793 SPEAKER TERMINAL
610 310 6588 ASSY,PWB,R-NET MR3B
RESISTOR
R1660 401 066 4019 OXIDE-MT 2.7 JA 2W
R1661 401 066 4019 OXIDE-MT 2.7 JA 2W
R1662 401 064 4813 OXIDE-MT 1.2 JA 2W
R1663 401 067 2816 OXIDE-MT 3.3 JA 2W
R1694 401 066 4019 OXIDE-MT 2.7 JA 2W
R1695 401 066 4019 OXIDE-MT 2.7 JA 2W
R1696 401 064 4813 OXIDE-MT 1.2 JA 2W
R1697 401 067 2816 OXIDE-MT 3.3 JA 2W
610 328 7386 ASSY,PWB,MAIN KE6B
TRANSISTOR
Q1861 405 014 4519 TR 2SC2412K T146 R
405 014 4618 TR 2SC2412K T146 S
405 015 8724 TR 2SC2812-L6-TB
405 015 8922 TR 2SC2812-L7-TB
405 163 1612 TR 2SC2812N-L6-TB0
Q2201 405 014 4519 TR 2SC2412K T146 R
405 014 4618 TR 2SC2412K T146 S
405 015 8724 TR 2SC2812-L6-TB
405 015 8922 TR 2SC2812-L7-TB
405 163 1612 TR 2SC2812N-L6-TB0
Q2202 405 014 4519 TR 2SC2412K T146 R
405 014 4618 TR 2SC2412K T146 S
405 015 8724 TR 2SC2812-L6-TB
405 015 8922 TR 2SC2812-L7-TB
405 163 1612 TR 2SC2812N-L6-TB0
Q2203 405 134 5925 TR 2SA1037AK-T146-R
405 147 2215 TR 2SA1037AK-S-T146
405 002 0318 TR 2SA1037K T146 R
405 002 0417 TR 2SA1037K T146 S
405 002 6726 TR 2SA1179-M6-TB
405 002 6924 TR 2SA1179-M7-TB
405 163 1513 TR 2SA1179N-M6-TB
Q2204 405 134 5925 TR 2SA1037AK-T146-R
405 147 2215 TR 2SA1037AK-S-T146
405 002 0318 TR 2SA1037K T146 R
405 002 0417 TR 2SA1037K T146 S
405 002 6726 TR 2SA1179-M6-TB
405 002 6924 TR 2SA1179-M7-TB
405 163 1513 TR 2SA1179N-M6-TB
Q2206 405 014 4519 TR 2SC2412K T146 R
405 014 4618 TR 2SC2412K T146 S
405 015 8724 TR 2SC2812-L6-TB
405 015 8922 TR 2SC2812-L7-TB
405 163 1612 TR 2SC2812N-L6-TB0
Q2207 405 014 4519 TR 2SC2412K T146 R
405 014 4618 TR 2SC2412K T146 S
405 015 8724 TR 2SC2812-L6-TB
405 015 8922 TR 2SC2812-L7-TB
405 163 1612 TR 2SC2812N-L6-TB0
Q2208 405 134 5925 TR 2SA1037AK-T146-R
405 147 2215 TR 2SA1037AK-S-T146
405 002 0318 TR 2SA1037K T146 R
405 002 0417 TR 2SA1037K T146 S
405 002 6726 TR 2SA1179-M6-TB
405 002 6924 TR 2SA1179-M7-TB
405 163 1513 TR 2SA1179N-M6-TB
Q2209 405 134 5925 TR 2SA1037AK-T146-R
405 147 2215 TR 2SA1037AK-S-T146
405 002 0318 TR 2SA1037K T146 R
405 002 0417 TR 2SA1037K T146 S
405 002 6726 TR 2SA1179-M6-TB
405 002 6924 TR 2SA1179-M7-TB
405 163 1513 TR 2SA1179N-M6-TB
Q241 405 014 4519 TR 2SC2412K T146 R
405 014 4618 TR 2SC2412K T146 S
405 015 8724 TR 2SC2812-L6-TB
405 015 8922 TR 2SC2812-L7-TB
405 163 1612 TR 2SC2812N-L6-TB0
Q242 405 014 4519 TR 2SC2412K T146 R
405 014 4618 TR 2SC2412K T146 S
405 015 8724 TR 2SC2812-L6-TB
405 015 8922 TR 2SC2812-L7-TB
405 163 1612 TR 2SC2812N-L6-TB0
Q243 405 014 4519 TR 2SC2412K T146 R
405 014 4618 TR 2SC2412K T146 S
405 015 8724 TR 2SC2812-L6-TB
405 015 8922 TR 2SC2812-L7-TB
405 163 1612 TR 2SC2812N-L6-TB0
Q2501 405 158 9210 TR IMZ4-T108
Q2502 405 158 9210 TR IMZ4-T108
Q2531 405 158 9210 TR IMZ4-T108
Q2532 405 158 9210 TR IMZ4-T108
Q2561 405 158 9210 TR IMZ4-T108
Q2562 405 158 9210 TR IMZ4-T108
Q261 405 014 4519 TR 2SC2412K T146 R
405 014 4618 TR 2SC2412K T146 S
405 015 8724 TR 2SC2812-L6-TB
405 015 8922 TR 2SC2812-L7-TB
405 163 1612 TR 2SC2812N-L6-TB0
405 173 9813 TR 2SC3928A1R
405 173 9912 TR 2SC3928A1S
Q262 405 014 4519 TR 2SC2412K T146 R
405 014 4618 TR 2SC2412K T146 S
405 015 8724 TR 2SC2812-L6-TB
405 015 8922 TR 2SC2812-L7-TB
405 163 1612 TR 2SC2812N-L6-TB0
Q263 405 134 5925 TR 2SA1037AK-T146-R
MAIN BOARD
R-NET BOARD
TERMINAL2 BOARD
TERMINAL1 BOARD
Key No. Part No. Description Key No. Part No. Description
