- 35 -
0 Total Dots 1980 0 ~ 3000 Read only
1 Disp Dots 1250 0 ~ 3000
2 H Back Porch 288 0 ~ 3000
3 V Back Porch 34 0 ~ 3000
4 Disp Line 700 0 ~ 1500
5-7 Not used
8 VSBEG 2 0 ~ 15
426 YCbCr (1080i-60)
0 Total Dots 2200 0 ~ 3000 Read only
1 Disp Dots 1872 0 ~ 3000
2 H Back Porch 232 0 ~ 3000
3 V Back Porch 54 0 ~ 3000
4 Disp Line 1050 0 ~ 1500
5-7 Not used
8 VSBEG 2 0 ~ 15
427 YCbCr (1035i)
0 Total Dots 2200 0 ~ 3000 Read only
1 Disp Dots 1872 0 ~ 3000
2 H Back Porch 232 0 ~ 3000
3 V Back Porch 90 0 ~ 3000
4 Disp Line 1012 0 ~ 1500
5-7 Not used
8 VSBEG 2 0 ~ 15
428 YCbCr (1080i-50)
0 Total Dots 2640 0 ~ 3000 Read only
1 Disp Dots 1872 0 ~ 3000
2 H Back Porch 232 0 ~ 3000
3 V Back Porch 54 0 ~ 3000
4 Disp Line 1050 0 ~ 1500
5-7 Not used
8 VSBEG 2 0 ~ 15
430 RGB Video (480i)
0 Total Dots 858 0 ~ 3000 Read only
1 Disp Dots 668 0 ~ 3000
2 H Back Porch 112 0 ~ 3000
3 V Back Porch 47 0 ~ 3000
4 Disp Line 456 0 ~ 1500
5-7 Not used
8 VSBEG 2 0 ~ 15
431 RGB Video (575i)
0 Total Dots 864 0 ~ 3000 Read only
1 Disp Dots 656 0 ~ 3000
2 H Back Porch 131 0 ~ 3000
3 V Back Porch 64 0 ~ 3000
4 Disp Line 534 0 ~ 1500
5-7 Not used
8 VSBEG 2 0 ~ 15
432 RGB Video (480P)
0 Total Dots 858 0 ~ 3000 Read only
1 Disp Dots 686 0 ~ 3000
2 H Back Porch 102 0 ~ 3000
3 V Back Porch 52 0 ~ 3000
4 Disp Line 460 0 ~ 1500
5-7 Not used
8 VSBEG 2 0 ~ 15
433 RGB Video (575P)
0 Total Dots 864 0 ~ 3000 Read only
1 Disp Dots 692 0 ~ 3000
2 H Back Porch 108 0 ~ 3000
3 V Back Porch 61 0 ~ 3000
4 Disp Line 550 0 ~ 1500
5-7 Not used
8 VSBEG 2 0 ~ 15
434 RGB Video (720P-60 )
0 Total Dots 1650 0 ~ 3000 Read only
1 Disp Dots 1250 0 ~ 3000
2 H Back Porch 278 0 ~ 3000
3 V Back Porch 34 0 ~ 3000
4 Disp Line 700 0 ~ 1500
5-7 Not used
8 VSBEG 2 0 ~ 15
435 RGB Video (720P-50 )
Electrical Adjustments
Group No. Adjustment Item Initial Value Range Input source / Description
