Page 38
- 38 -
6
Alpha Brightness
/120/120/120/120
/120/120/120
120/120/120/120
7
Alpha Color
/120/120/120/120
/120/120/120
10/10/10/10
8
Alpha Tint
/10/10/10/10
/10/10/10
10/10/10/10
9
Alpha Sharpness
/10/10/10/10
/10/10/10
680
Auto Calibration
0
Execute Calibration
0
0 ~ 1
Execute Auto Calibration when the value changes.
1
Loop Count
3
1 ~ 30
Maximum Loop with OFFSET --> GAIN
2
OFFSET AREA H START
975
0 ~ 1000
3
OFFSET AREA V START
500
0 ~ 1000
4
GAIN AREA H START
25
0 ~ 1000
5
GAIN AREA V START
500
0 ~ 1000
6
Image AREA H WIDTH
13
0 ~ 4095
7
Image AREA V HEIGHT
9
0 ~ 4095
8
OFFSET target
1
0 ~ 127
9
OFFSET tolerance
1
1 ~ 127
10
GAIN target
235
0 ~ 255
White level adjustment target value
11
GAIN tolerance
1
1 ~ 255
White level adjustment tolerance range
12
Auto Status
0
0 / 1 / 9
Read only (0: Finish correctly, 1: On Calibration, 9: Finish with error)
13
AutoWait
1
1 ~ 20
Wait value for each settings
14
CHECK -Tolerance
1
1 ~ 255
Offset tolerance
681
Auto PC Adjustment
0
AutoPCAdjustEnable
0
0 ~ 1
0: Auto PC adj. enable, 1: Auto PC adj. prohibited
1
Frequency Step
1
0 ~ 3
Frequency step in total dot search
2
Frequency Threshold
5
0 ~ 10
Confirm total dot (0: fine, ... , 10: no good)
3
Fine Phase
0
0 ~ 1
Executes phase after total dot adj. (0: fine, 1: not executed)
4
BLKDET
1
0 ~ 3
Detection area of blank level
5
PHASEMSK
0
0 ~ 3
Phase detection filter
(0: effective all bits, 1: disable lower 1 bit, 2: disable lower 2 bits, 3: disable lower 3 bits)
690
CUSTOM (Aspect)
0
Connect
0
0 ~ 1
individual/Link edition (0: individual, 1: link)
1
Horizontal Scaler
100
0 ~ 200
H-scaler edition
2
Horizontal Position
100
0 ~ 200
H-position correction
3
RESET/STORE
0
0 ~ 1
Reset or Save of H-aspect (0: reset, 1: save)
4
Vertical Scaler
100
0 ~ 200
V-scaler edition
5
Vertical Position
100
0 ~ 200
V-position correction
6
RESET/STORE
0
0 ~ 1
Reset/ or Save of H-aspect (0: reset, 1: save)
7
Screen Select
0
0 ~ 1
Screen mode selection (0: FULL, 1: NORMAL)
8
CUSTOM ON/OFF
0
0 ~ 1
Custom (0: disable, 1: enable)
700
General
0
IP Mode
1
0 ~ 1
Setting at IP OFF (0: not used for IP block, 1: OFF with IP block)
1
3:2 PullDown Mode
1
1 ~ 3
bit0: global motion, bit1: video motion
2
Detect Film Mode Enable
0
0 ~ 2
0 : 2:3pull down & 2:2pull down, 1 : 2:3pull down, 2 : 2:2pull down
3
Force IP Mode
2
0 ~ 2
0 : IP Process Disable, 1 : Force Normal IP Mode, 2 : Force Film Mode
701
De-interlacer setting
Progressive ON / Film
0
Motion Adaptive Weight Value
25
0 ~ 255
1
Angle Interpolation Level
2
0 ~ 4
0 : Conservative <----> 4 : Aggressive
2
CUE Low Pass Filter Enable
0
0 ~ 1
711
Noise Reduction
N.R L1
0
Noise Pixel Range
1
0 ~ 2
1
Noise Region 0
12
0 ~ 1023
2
Noise Region 1
24
0 ~ 1023
3
Noise Region 2
40
0 ~ 1023
4
Noise Gain Level
50
0 ~ 255
713
Noise Reduction
N.R L2
0
Noise Pixel Range
1
0 ~ 2
1
Noise Region 0
12
0 ~ 1023
2
Noise Region 1
24
0 ~ 1023
3
Noise Region 2
40
0 ~ 1023
4
Noise Gain Level
100
0 ~ 255
715
Noise Reduction
N.R OFF
0
Noise Pixel Range
1
0 ~ 2
1
Noise Region 0
12
0 ~ 1023
2
Noise Region 1
24
0 ~ 1023
3
Noise Region 2
40
0 ~ 1023
4
Noise Gain Level
1
0 ~ 1023
Electrical Adjustments
Group No. Adjustment Item
Initial Value
Range
Input source / Description
