Electrical adjustments – Eiki LC-X71 LC-X71L User Manual
Page 33
- 33 -
15
CM_IsAccess
1
0 ~ 1
For debug
310
AD9882
0
GREEN_OFFSET
63
0 ~ 127
1
RED_OFFSET
63
0 ~ 127
2
BLUE_OFFSET
63
0 ~ 127
3
GREEN_GAIN
78
0 ~ 255
4
RED_GAIN
78
0 ~ 255
5
BLUE_GAIN
78
0 ~ 255
6
BANDWIDTH
1
0 ~ 1
Analog
7
Last Calib Table [Offset]
255
0 ~ 6
Frequency range at auto calibration (Read only)
(0: below Thresh 0, 1: Thresh 0-1, 2: Thresh 1-2, ... , 6: over Thresh 5), Auto calib = 255
8
Last Calib Table [Gain]
255
0 ~ 6
Frequency range at auto calibration (Read only)
Read only, (0: below Thresh 0, 1: Thresh 0-1, 2: Thresh 1-2, ... , 6: over Thresh 5), Auto calib = 255
9
OFFSET_THRESH_0
70
0 ~ 255
[MHz]
10
OFFSET_THRESH_1
80
0 ~ 255
11
OFFSET_THRESH_2
85
0 ~ 255
12
OFFSET_THRESH_3
100
0 ~ 255
13
OFFSET_THRESH_4
120
0 ~ 255
14
OFFSET_THRESH_5
140
0 ~ 255
15
GAIN_THRESH_0
70
0 ~ 255
16
GAIN_THRESH_1
80
0 ~ 255
17
GAIN_THRESH_2
85
0 ~ 255
18
GAIN_THRESH_3
100
0 ~ 255
19
GAIN_THRESH_4
120
0 ~ 255
20
GAIN_THRESH_5
140
0 ~ 255
21
OFFSET R 0 Under
121
0 ~ 255
22
OFFSET R 0-1
123
0 ~ 255
23
OFFSET R 1-2
124
0 ~ 255
OFFSET Threshold
24
OFFSET R 2-3
128
0 ~ 255
Differential data between X-X
25
OFFSET R 3-4
131
0 ~ 255
26
OFFSET R 4-5
131
0 ~ 255
27
OFFSET R 5 Over
128
0 ~ 255
28
OFFSET G 0 Under
123
0 ~ 255
29
OFFSET G 0-1
124
0 ~ 255
30
OFFSET G 1-2
125
0 ~ 255
31
OFFSET G 2-3
128
0 ~ 255
32
OFFSET G 3-4
131
0 ~ 255
33
OFFSET G 4-5
130
0 ~ 255
34
OFFSET G 5 Over
128
0 ~ 255
35
OFFSET B 0 Under
126
0 ~ 255
36
OFFSET B 0-1
125
0 ~ 255
37
OFFSET B 1-2
126
0 ~ 255
38
OFFSET B 2-3
128
0 ~ 255
39
OFFSET B 3-4
132
0 ~ 255
40
OFFSET B 4-5
133
0 ~ 255
41
OFFSET B 5 Over
128
0 ~ 255
42
GAIN R 0 Under
129
0 ~ 255
43
GAIN R 0-1
129
0 ~ 255
44
GAIN R 1-2
129
0 ~ 255
GAIN Threshold
45
GAIN R 2-3
128
0 ~ 255
Differential data between X-X
46
GAIN R 3-4
127
0 ~ 255
47
GAIN R 4-5
126
0 ~ 255
48
GAIN R 5 Over
128
0 ~ 255
49
GAIN G 0 Under
129
0 ~ 255
50
GAIN G 0-1
129
0 ~ 255
51
GAIN G 1-2
129
0 ~ 255
52
GAIN G 2-3
128
0 ~ 255
53
GAIN G 3-4
127
0 ~ 255
54
GAIN G 4-5
126
0 ~ 255
55
GAIN G 5 Over
128
0 ~ 255
56
GAIN B 0 Under
130
0 ~ 255
57
GAIN B 0-1
127
0 ~ 255
58
GAIN B 1-2
127
0 ~ 255
59
GAIN B 2-3
128
0 ~ 255
60
GAIN B 3-4
128
0 ~ 255
61
GAIN B 4-5
127
0 ~ 255
62
GAIN B 5 Over
128
0 ~ 255
311
M62393FP
0
R_CLAMP
0
0 ~ 255
1
G_CLAMP
0
0 ~ 255
2
B_CLAMP
0
0 ~ 255
400
Composite (NTSC)
Electrical Adjustments
Group No. Adjustment Item
Initial Value
Range
Input source / Description
