- 55 -
206
NET_SW
Switch On/Off for PJ-Net Power
L:On, H: Off
O
207 GND
Power
for
Inout/Output(0V)
-
-
208
FPGA_CLB
Initialize for circuit
H after config.
O
209 3.3V
Power
for
Inout/Output(3.3V)
-
-
210
SYS SW_CPU
Bus Switch
O
211
IC_RESET_CPU
Power Control peripheral ICs
O
212
LAMP_SWIN
Lamp Drive
H: On, L: Off
O
213
FAN_DRIVE_CPU
Fan Drive
O H: On, L: Off
O
214
SH_SDA_3V
IIC Bus (standby Off)
L: Active
I/O
215
SH_SCL_3V
IIC Bus (standby Off)
L: Active
I/O
216
SH_SDA_S3V
IIC Bus (always On)
L: Active
I/O
217
SH_SCL_S3V
IIC Bus (always On)
L: Active
I/O
218
PW_SH_0
PW-SH Input Signal
I
219
UCLK
USB Clock [48MHz]
(Pull-up)
I
220
RESETP
Power On Reset Request
L: On reset
I
221 (Not
used)
(Pull-up)
-
222
MD3
Bus Width Setting for Area0
L fixed
I
223
MD4
Bus Width Setting for Area0
L fixed
I
224 3.3V
Test(3.3V
Fixed)
-
I
225 3.3V
USB
Analog
Power(3.3V)
-
-
226 (USB1P)[Func]
USB1
Data
I/O(+)
(Open)
I/O
227 (USB1M)[Func]
USB1
Data
I/O(-)
(Open)
I/O
228
GND USB
Analog Power (0V)
-
-
229 (USB2P)[Host]
USB2
Data
I/O(+)
(Open)
I/O
230 (USB2M)[Host]
USB2
Data
I/O(-)
(Open)
I/O
231 3.3V
USB
Analog
Power(3.3V)
-
-
232 GND
Analog
Power
(0V)
-
-
233
PRESS_SENS
Input for Pressure Sensor
Analog Input
AI
234
ACCELE_SENS
Input for Acceleration Sensor
Analog Input
AI
235
KEY1
KEY AD Converter Input
Analog Input
AI
236
KEY2
KEY AD Converter Input
Analog Input
AI
237 3.3V
Analog
Power(3.3V)
-
-
238
KEY3
KEY AD Converter Input
Analog Input
AI
239 OPT1
Option
Input
Analog
Input
AI
240 GND
Analog
Power
(0V)
-
-
Pin No.
Function Name
Function
Polarity
I/O
Control Port Functions
