Electrical adjustments – Eiki LC-X71 LC-X71L User Manual
Page 36
- 36 -
0
Total Dots
1980
0 ~ 3000
Read only
1
Disp Dots
1250
0 ~ 3000
2
H Back Porch
276
0 ~ 3000
3
V Back Porch
34
0 ~ 3000
4
Disp Line
700
0 ~ 1500
5-7
Not used
8
VSBEG
2
0 ~ 15
436
RGB Video (1080i-60)
0
Total Dots
2200
0 ~ 3000
Read only
1
Disp Dots
1872
0 ~ 3000
2
H Back Porch
220
0 ~ 3000
3
V Back Porch
54
0 ~ 3000
4
Disp Line
1050
0 ~ 1500
5-7
Not used
8
VSBEG
2
0 ~ 15
437
RGB Video (1035i)
0
Total Dots
2200
0 ~ 3000
Read only
1
Disp Dots
1872
0 ~ 3000
2
H Back Porch
220
0 ~ 3000
3
V Back Porch
90
0 ~ 3000
4
Disp Line
1012
0 ~ 1500
5-7
Not used
8
VSBEG
2
0 ~ 15
438
RGB Video (1080i-50)
0
Total Dots
2640
0 ~ 3000
Read only
1
Disp Dots
1872
0 ~ 3000
2
H Back Porch
220
0 ~ 3000
3
V Back Porch
54
0 ~ 3000
4
Disp Line
1050
0 ~ 1500
5-7
Not used
8
VSBEG
2
0 ~ 15
440
HDCP (480P)
0-6
Not used
7
OverScan
0
0 ~ 255
Over Scan Rate (0~25.5% : 0.1%Step)
8
VSBEG
2
0 ~ 15
441
HDCP (575P)
0-6
Not used
7
OverScan
0
0 ~ 255
Over Scan Rate (0~25.5% : 0.1%Step)
8
VSBEG
2
0 ~ 15
442
HDCP (720P-60 )
0-6
7
OverScan
0
0 ~ 255
Over Scan Rate (0~25.5% : 0.1%Step)
8
VSBEG
2
0 ~ 15
443
HDCP (720P-50 )
0-6
7
OverScan
0
0 ~ 255
Over Scan Rate (0~25.5% : 0.1%Step)
8
VSBEG
2
0 ~ 15
444
HDCP (1080i-60)
0-6
7
OverScan
0
0 ~ 255
Over Scan Rate (0~25.5% : 0.1%Step)
8
VSBEG
2
0 ~ 15
445
HDCP (1035i)
0-6
7
OverScan
0
0 ~ 255
Over Scan Rate (0~25.5% : 0.1%Step)
8
VSBEG
2
0 ~ 15
446
HDCP (1080i-50)
0-6
7
OverScan
0
0 ~ 255
Over Scan Rate (0~25.5% : 0.1%Step)
8
VSBEG
2
0 ~ 15
447
HDCP (1080-30psf)
0-6
7
OverScan
0
0 ~ 255
Over Scan Rate (0~25.5% : 0.1%Step)
8
VSBEG
2
0 ~ 15
448
HDCP (1080-25psf)
0-6
7
OverScan
0
0 ~ 255
Over Scan Rate (0~25.5% : 0.1%Step)
8
VSBEG
2
0 ~ 15
449
HDCP (1080-24psf)
0-6
7
OverScan
0
0 ~ 255
Over Scan Rate (0~25.5% : 0.1%Step)
8
VSBEG
2
0 ~ 15
450
RGB-Video (1080-30psf)
Electrical Adjustments
Group No. Adjustment Item
Initial Value
Range
Input source / Description
