28 Real G_GAM_BRT 0 -4096 ~ 4095 Differential data of white balance adjustment at Real mode
29 Real B_GAM_BRT 0 -4096 ~ 4095
30 Real R_GAM_BRT 0 -4096 ~ 4095
31 Real G_BRT_CTRL 0 -128 ~ 127 Differential data of white-white level adjustment at Real mode
32 Real B_BRT_CTRL 0 -128 ~ 127
33 Real R_BRT_CTRL 0 -128 ~ 127
210 Adjustment for AV input
0-14 - - Not used
15 G_GAM_BRT 0 -4096 ~ 4095 ✻ AV Gamma-shift adjustment
16 B_GAM_BRT 0 -4096 ~ 4095 ✻ AV white balance adjustment [B]
17 R_GAM_BRT 0 -4096 ~ 4095 ✻ AV white balance adjustment [R]
18 USR_GAIN 32 1 ~ 255 AV,RGB-VIDEO,HDCP
19 G_SUB_GAIN 128 0 ~ 255 White 100% adjustment
20 B_SUB_GAIN 128 0 ~ 255
21 R_SUB_GAIN 128 0 ~ 255
22 G_SUB_BRT 0 -4096 ~ 4095
23 B_SUB_BRT 0 -4096 ~ 4095
24 R_SUB_BRT 0 -4096 ~ 4095
25 G_BRT_CTRL 0 0 ~ 255 White-white level adjustment
26 B_BRT_CTRL 0 0 ~ 255
27 R_BRT_CTRL 0 0 ~ 255
28 Cinema G_GAM_BRT 0 -4096 ~ 4095 Differential data of white balance adjustment at Cinema mode
29 Cinema B_GAM_BRT 0 -4096 ~ 4095
30 Cinema R_GAM_BRT 0 -4096 ~ 4095
31 Cinema G_BRT_CTRL 0 -128 ~ 127 Differential data of white-white level adjustment at Cinema mode
32 Cinema B_BRT_CTRL 0 -128 ~ 127
33 Cinema R_BRT_CTRL 0 -128 ~ 127
290 PANEL L/R setting
0 PANEL_LR - - Read only [ 0: Type-L, 20: Type-R ]
1
300 CXD3807
Component, SCART input gain adjustment
0 Component Y Level 118/ 0 ~ 255 Group 01 : 1080i-60, 1080i-50, 1035i, 1080i-60, 1080i-50, 1035i
118/ Group 02 : 720p-60, 720p-60,720p-60, 720p-50
118/ Group 03 : 480p, 575p, 480p, 575p
118 Group 04 : 480i, 575i, 480i, 575i, 480i, 575i
1 Component C Level 118/118/118/118 Component, SCART input gain adjustment
2 CVBS Y Level 162/157 0 ~ 255 CVBS, Y input gain adjustment (Composite / S-VIDEO)
3 CVBS C Level 115/110 0 ~ 255 C input gain adjustment(Composite / S-VIDEO)
4 Sub Hue 32 0 ~ 63 CVBS/S
5 HS Slice Level 4 0 ~ 15 H Sync
6 HS Slice Offset 5 0 ~ 15 H Sync
7 VS Slice Level 6 0 ~ 15 V Sync
8 VS Slice Offset 6 0 ~ 15 V Sync
9 Sampling Phase 0 0 ~ 63 A/D
10 Pre Shoot Level 8 0 ~ 15
11 Over Shoot Level 8 0 ~ 15
Y input filter setting
12 Y Filter 5/5/6 0 ~ 7 Group 01 : Composite, S-Video
Group 02 : 480i, 575i, 480p, 575p
Group 03 : 720p-60, 720p-50, 1035i, 1080i-60, 1080i-50
13 C Filter 5/5/6 0 ~ 7 C input filter setting
14 NTSC/PAL Detect 2 0 ~ 3 NTSC/PAL detect threshold setting ( 0 : 64H/1V - PAL, 1 : 96H/1V, 2 : 128H/1V, 3 : 160H/1V - PAL)
301 TA1370
0 Sepa Level 2 0 ~ 3 Sync separation level switch
302 FPGA
0 FPGA_DEMO_ON_OFF 0 0 ~ 1 Demo mode On/Off (0: Off, 1: On)
1 FPGA_DEMO_MODE 0 0 ~ 3 Demo mode switch (0: Demo0, 1:Demo1, etc.)
303 FPGA (Color Manag.)
0 Y Range 8 0 ~ 32
1 HueRange 10 0 ~ 20
2 GainRange 30 0 ~ 50
3 GM_MinSlope 3 0 ~ 10
4 GM_MaxSlope 18 10 ~ 30
5 GM_Converge 3 1 ~ 5
6-7 - - Not used
8 COLM_GET_KIND_Y_ud 9 1 ~ 9
9-10 - - Not used
11 SameHue 3 1 ~ 10
12 Cut_UVNorm 5 0 ~ 64
13 Cur_MinY 0 0 ~ 127
14 Cur_MaxY 255 128 ~ 255
Electrical Adjustments
Group No. Adjustment Item Initial Value Range Input source / Description
