HP LaserJet Enterprise M806x+ Black and White Laser Printer User Manual
Page 76
Step three: Install the optional or replacement booklet maker accessory
1.
If installing an optional booklet maker for the first time, turn off the product and disconnect the power
cord.
CAUTION:
To avoid damage to the product, turn the product off, wait five seconds, and then remove
the power cord before attempting to service the product.
a.
Remove two thumbscrews.
b.
Remove one cover (callout 1). Release one tab, and then remove tray one (callout 2).
c.
Install the IPTU (callout 1), and then install the binder cover (callout 2).
68
Chapter 2 Install and configure the finishing accessories
ENWW
