32 chapter 1 finishing accessory overview enww – HP LaserJet Enterprise M806x+ Black and White Laser Printer User Manual

Page 40

background image

3

Stapler/stacker output slots

4

Lower booklet door (access for clearing jams)

5

Front left door

6

Stapler 1

7

Lower paper delivery guide

8

Upper paper delivery guide

9

Top left door

10

Hole-punch unit (hole punch models only)

11

Hole-punch alignment knob (hole punch models only)

12

Chad collector (hole punch models only)

13

Hole-punch door (hole punch models only)

14

Saddle-stitch carriage, access to stapler 2 and 3

15

Paper-advancement knobs for clearing jams

32

Chapter 1 Finishing accessory overview

ENWW
