Install or replace a stapler/stacker with booklet maker
accessory for the HP LaserJet Enterprise M806 and HP LaserJet
Enterprise flow MFP M830
● Introduction
● Before you begin
● Required tools
● Step one: Remove the booklet maker
● Step two: Unpack the optional or replacement booklet maker accessory
● Step three: Install the optional or replacement booklet maker accessory
● Step four: Parts return
● Step five: Configure the booklet maker in the HP Embedded Web Server (EWS)
● Step six: Configure the default staple location
Introduction
The following information provides the procedures to install or replace a booklet maker kit for the HP
LaserJet Enterprise M806 and HP LaserJet Enterprise flow MFP M830.
NOTE: To see a short video demonstrating this procedure, click here .
Before you begin
Use the table below to identify the correct accessory part number for the accessory, and then go to
www.hp.com/buy/parts to order the accessory.
Table 2-2 Booklet maker accessory part numbers
CZ285A Stapler/stacker with booklet maker accessory with installation instructions
To replace an existing booklet maker, go to Step one: Remove the booklet maker on page 47 .
To install a new booklet maker, go to Step two: Unpack the optional or replacement booklet maker accessory
on page 48 .
Required tools
No special tools are required to install this accessory.
Step one: Remove the booklet maker
1. Turn off the product, and then disconnect the power cord
CAUTION: Turn the product off, wait five seconds, and then remove the power cord before attempting
to service the product.
