Channel Group Name Description Default
value Notes
171 EXECUTE
13 Image Size 0 to 255 Scaled as % of
total control range, which
is 200 to 4000 67
14 Image Vertical
Stretch 0 to 255 Scaled as % of
total control range, which
is 200 to 3000 91
15 Macro Function Projector Orientation
0-9 Front Projection
10-19 Rear Projection
20-29 Front Projection
Inverted
30-39 Rear Projection
Inverted
—
On Screen Display
40-59 OSD On
50-59 OSD Off
60-69 Lens Calibrate
—
86 LOAD
—
Test Pattern
100-104 Off105-109 Grid
110-114 Grey Scale 16
115-119 White
120-124 Flat Grey
125-129 Black
130-134 Checker
135-139 13 Point
140-144 Color Bars
145-149 Aspect Ratio
150-154 Edge Blend
155-159 Boresight
—
171 EXECUTE
—
Image Freeze
200-209 Freeze image
210-219 Unfreeze image 255 Lens Calibrate is locked by
channel
“Lens shift enable”.
DMX/ArtNET
