Channel Group Name Description Default
value Notes
172-255 Live video
(Picture mute OFF) brightness channel can be
used to achieve the same
effect.
3 Lens Shutter 0-85 Shutter Closed (Black
Screen)
172-255 Shutter Open
(Live Video) 255
4 Lens Lens shift
enable 0-85 Lens shift disable
172-255 Lens shift enable 255 Lock all lens motors.
5 Lens Zoom
(Coarse) 0 to 255 Scaled as % of
total control range, which
is 0 to 2100 128 Locked by channel
“Lens shift enable”
6 Lens Zoom (Fine) 0
7 Lens Focus
(Coarse) 0 to 255 Scaled as % of
total control range, which
is 0 to 2100 128 Locked by channel
“Lens shift enable”
8 Lens Focus (Fine) 0
9 Lens Lens
Horizontal
position
(Coarse) 0 to 255 Scaled as % of
total control range, which
is 0 to 4096 128 Locked by channel
“Lens shift enable”
10 Lens Lens
Horizontal
position
(Fine) 0
11 Lens Lens Vertical
position
(Coarse) 0 to 255 Scaled as % of
total control range, which
is 0 to 4096 Locked by channel
“Lens shift enable”
12 Lens Lens Vertical
position
(Fine)
13 Input Channel Projector Channel
Selection
0 to 9 Projector Channel 1
10 to 19 Projector Channel
2
20 to 29 Projector Channel
3
....
180 to 189 Projector
Channel 19
190 to 199 Projector
Channel 20 255
14 Input Input Input Selection 255 Does not change input on
default.
DMX/ArtNET
