5.7 DNP Slave Subset Definition
OBJECT REQUES
T RESPONSE
Obj Var Description Func
Codes Qual
Codes
(hex) Func
Codes Qual
Codes
(hex) Data
Size
(bits
) NOTES
1 0 Binary Input - All Variations 1 06 1 Slave will return variation
1 data
1 Binary Input 1 06 129,
130 00, 01 1 Slave will return this
variation
2 Binary Input with Status 129,
130 00, 01 8 Slave will return Unknown
Object to this request
2 0 Binary Input Change - All
Variations 1 06, 07,
08 56 Slave will return variation
2 data
1 Binary Input Change Without
Time 1 06, 07,
08 129,
130 17, 28 8 Slave will return this
variation
2 Binary Input Change With
Time 1 06, 07,
08 129,
130 17, 28 56 Slave will return this
variation
3 Binary Input Change With
Relative Time 1 06, 07,
08 129,
130 17, 28 24 Slave will parse this
message and return no
data
10 0 Binary Output - All Variations 1 06 8 Slave will return variation
2 data
1 Binary Output 1 Slave will return Unknown
Object to this request
2 Binary Output Status 1 06 129,
130 00, 01 8 Slave will return this
variation
12 0 Control Block - All Variations 88 Slave will use variation 1
control
1 Control Relay Output Block 3, 4, 5, 6 17, 28 129 Echo of
request 88 Slave will respond
correctly to this variation
2 Pattern Control Block 88 Slave will return Unknown
Object to this request
3 Pattern Mask 16 Slave will return Unknown
Object to this request
20 0 Binary Counter - All
Variations 1, 7, 8, 9,
10 06 32 Slave will return variation
5 data
1 32-Bit Binary Counter 129,
130 00, 01 40 Slave will return Unknown
Object to this request
2 16-Bit Binary Counter 129,
130 00, 01 24 Slave will return Unknown
Object to this request
3 32-Bit Delta Counter 129,
130 00, 01 40 Slave will return Unknown
Object to this request
4 16-Bit Delta Counter 129,
130 00, 01 24 Slave will return Unknown
Object to this request
5 32-Bit Binary Counter
Without Flag 1, 7, 8, 9,
10 06 129,
130 00, 01 32 Slave will return this
variation
