OBJECT
REQUEST
RESPONSE
Obj
Var Description
Func
Codes
Qual
Codes
(hex)
Func
Code
s
Qual
Codes
(hex)
Data
Size
(bits
)
NOTES
8
16-Bit Delta Counter Change
Event With Time
72
23
0
Frozen Counter Event - All
Variations
1
32-Bit Frozen Counter Event
Without Time
40
2
16-Bit Frozen Counter Event
Without Time
24
3
32-Bit Frozen Delta Counter
Event Without Time
40
4
16-Bit Frozen Delta Counter
Event Without Time
24
5
32-Bit Frozen Counter Event
With Time
88
6
16-Bit Frozen Counter Event
With Time
72
7
32-Bit Frozen Delta Counter
Event With Time
88
8
16-Bit Frozen Delta Counter
Event With Time
72
30
0
Analog Input - All Variations
1
06
16
Master will generate this
variation
1
32-Bit Analog Input
1
06
129,
130
00, 01
40
Master will generate and
process this variation
2
16-Bit Analog Input
1
06
129,
130
00, 01
24
Master will generate and
process this variation
3
32-Bit Analog Input Without
Flag
1
06
129,
130
00, 01
32
Master will generate and
process this variation
4
16-Bit Analog Input Without
Flag
1
06
129,
130
00, 01
16
Master will generate and
process this variation
31
0
Frozen Analog Input - All
Variations
1
32-Bit Frozen Analog Input
40
2
16-Bit Frozen Analog Input
24
3
32-Bit Frozen Analog Input
With Time To Freeze
88
4
16-Bit Frozen Analog Input
With Time To Freeze
72
5
32-Bit Frozen Analog Input
Without Flag
32
6
16-Bit Frozen Analog Input
Without Flag
16
32
0
Analog Change Event - All
Variations
1
06, 07,
08
24
Master will generate this
variation
